JEM Pro-Fog Fluid, Extra Quick Dissipating

PREMIUM FOG FLUID

Larger Images

JEM™ Pro-Fog Fluid, Extra Quick Dissipating is a specially formulated water-based fog fluid for use in applicable JEM fog machines. JEM Pro-Fog Fluid, Extra Quick Dissipating fluid is specifically designed to simulate steam or CO2 effects such as ‘cyro’ cannons and jets. JEM Pro-Fog Fluid, Extra Quick Dissipating creates a semi-translucent white burst of fog, but dissipates ultra-fast to mimic the characteristics of CO2.

Available in 2.5, 5, 9.5, 25, and 220 l containers.





  • EXTRA QUICK DISSIPATION

    When you need a semi-translucent burst of fog to draw attention, but also need it to disperse ultra-fast, accept no substitution—JEM Pro-Fog Fluid, Extra Quick Dissipation. This water-based fog fluid is designed to mimic steam or CO2 effects such as cyro cannons and jets without the hassle of actually using CO2. When used in combination with a JEM brand fog machine the effect will be visually stunning.

  • PREMIUM EFFECTS FLUIDS BY MARTIN

    Martin fluids are produced at our state-of-the-art, semi-automated fluid production facility in the United Kingdom. A virtually sterile environment is our guarantee of a pure and precise product that delivers the same effect over and over again. This means that Martin fluid never comes in contact with the environment, or humans, thereby ensuring a 100% bacteria free and sterile fluid. Our production facility is ISO 9001 accredited, an internationally recognized standard of quality in manufacturing standards, documentation and administrative procedures ensuring superior quality and safety of the materials being used in our fluids. Nowhere else in the industry will you find the same attention to detail, safety and environmental consciousness. Martin fluids are also widely available throughout the world ensuring your show will go on.

  • FLUID THAT WE STAND BY

    If you think all fog fluids are the same, think again. JEM Pro-Fog Fluid has been crafted to deliver exceptional results including our benchmark density, dissipation, and pure white colors. Our manufacturing process removes all mineral content from the fluid, ensuring little residue is left behind on your prized equipment and performance surfaces. We also use the highest-grade active ingredients, and microprocessor-controlled heat exchangers to ensure that fog is produced safely for you and your audience.

  • GALLONS VS. LITERS

    Why do we use liters instead of gallons? Because it’s the European way and by selling our fluid in liter containers we can offer 20% more fluid than a standard US gallon. We don’t raise our price because of this, so you are getting that extra 20% gratis. You’re welcome! We offer our fluid in various size containers, best suited for your applications, 2.5 l, 5 l, 9.5 l, 25 l, and even the large 220 l barrels. Pick the size that’s right for your show and your budget.

EXTRA QUICK DISSIPATION

When you need a semi-translucent burst of fog to draw attention, but also need it to disperse ultra-fast, accept no substitution—JEM Pro-Fog Fluid, Extra Quick Dissipation. This water-based fog fluid is designed to mimic steam or CO2 effects such as cyro cannons and jets without the hassle of actually using CO2. When used in combination with a JEM brand fog machine the effect will be visually stunning.

PREMIUM EFFECTS FLUIDS BY MARTIN

Martin fluids are produced at our state-of-the-art, semi-automated fluid production facility in the United Kingdom. A virtually sterile environment is our guarantee of a pure and precise product that delivers the same effect over and over again. This means that Martin fluid never comes in contact with the environment, or humans, thereby ensuring a 100% bacteria free and sterile fluid. Our production facility is ISO 9001 accredited, an internationally recognized standard of quality in manufacturing standards, documentation and administrative procedures ensuring superior quality and safety of the materials being used in our fluids. Nowhere else in the industry will you find the same attention to detail, safety and environmental consciousness. Martin fluids are also widely available throughout the world ensuring your show will go on.

FLUID THAT WE STAND BY

If you think all fog fluids are the same, think again. JEM Pro-Fog Fluid has been crafted to deliver exceptional results including our benchmark density, dissipation, and pure white colors. Our manufacturing process removes all mineral content from the fluid, ensuring little residue is left behind on your prized equipment and performance surfaces. We also use the highest-grade active ingredients, and microprocessor-controlled heat exchangers to ensure that fog is produced safely for you and your audience.

GALLONS VS. LITERS

Why do we use liters instead of gallons? Because it’s the European way and by selling our fluid in liter containers we can offer 20% more fluid than a standard US gallon. We don’t raise our price because of this, so you are getting that extra 20% gratis. You’re welcome! We offer our fluid in various size containers, best suited for your applications, 2.5 l, 5 l, 9.5 l, 25 l, and even the large 220 l barrels. Pick the size that’s right for your show and your budget.

Features

  • Water-based fluid formula leaves little residue
  • Produced with ultra-pure, de-ionized water
  • Ultra-fast dispersion time to mimic CO2 effects
  • Transparent white color
  • Available in various size containers to suit your needs
  • For use in all compatible Martin fog effect generators

Specifications

  • Physical JEM Pro-Fog Fluid, Extra Quick Dissipating, 2.5 l:

    Bottle: P/N 97120901-00
    Case: P/N 97120901
    Bottle dimensions, 2.5 l (L x W x H): 140 x 110 x 216 mm (5.5 x 4.3 x 8.5 in.)
    Bottle weight: 2.6 kg (5.8 lb.)
    Pieces per case: 4
    Case dimensions (L x W x H): 280 x 220 x 250 mm (11 x 8.7 x 9.8 in.)
    Weight of case: 12 kg (27 lb.)
    Cases per pallet: 48
    Pallet dimensions (L x W x H): 1200 x 800 x 1200 mm (47.3 x 31.5 x 47.3 in.)
    Weight of pallet quantity: 589 kg (1299 lb.)

    JEM Pro-Fog Fluid, Extra Quick Dissipating, 5 l:

    Bottle: P/N 97120902-00
    Case: P/N 97120902
    Bottle dimensions, 5 l: 186 x 132 x 280 mm (7.3 x 5.2 x 11 in.)
    Bottle weight: 5.1 kg (11.3 lb.)
    Pieces per case: 4
    Case dimensions (L x W x H): 370 x 290 x 300 mm (14.6 x 11.4 x 11.8 in.)
    Weight of case: 22 kg (49 lb.)
    Cases per pallet: 30
    Pallet dimensions (L x W x H): 1200 x 800 x 1400 mm (47.3 x 31.5 x 47.3 in.)
    Weight of pallet quantity: 673 kg (1484 lb.)

    JEM Pro-Fog Fluid, Extra Quick Dissipating, 9.5 l:

    P/N 97120900
    Bottle dimensions, 9.5 l: 250 x 245 x 231 mm (9.8 x 9.6 x 9.1 in.)
    Bottle weight: 9.6 kg (21.2 lb.)
    Packaged bottle dimensions (L x W x H): 260 x 260 x 250 mm (10.3 x 10.3 x 9.9 in.)
    Weight of package: 10 kg (22.1 lb.)
    Packages per pallet: 48
    Pallet dimensions (L x W x H): 1200 x 800 x 1350 mm (47.3 x 31.5 x 53.2 in.)
    Pallet weight: 495 kg (1092 lb.)

    JEM Pro-Fog Fluid, Extra Quick Dissipating, 25 l:

    P/N 97120903
    Container dimensions, 25 l (L x W x H): 440 x 270 x 250 mm (17.4 x 10.7 x 9.9 in.)
    Weight of container: 26 kg (58 lb.)
    No outer packaging
    Containers per pallet: 24
    Pallet dimensions (L x W x H): 1200 x 800 x 1400 mm (47.3 x 31.5 x 47.3 in.)
    Weight of pallet quantity: 639 kg (1409 lb.)

    JEM Pro-Fog Fluid, Extra Quick Dissipating, 220 l:

    P/N 97120904
    Container dimensions, 220 l (L x W x H): 600 x 600 x 900 mm (23.7 x 23.7 x 35.5 in.)
    Weight of container : 230 kg (508 lb.)
    No outer packaging
    Containers par pallet: 2
    Pallet dimensions (L x W x H): 1200 x 800 x 1100 mm (47.3 x 31.5 x 47.3 in.)
    Weight of pallet quantity: 475 kg (1048 lb.)

    Thermal Minimum operating temperature (Ta min): 5° C (41° F) Maximum ambient temperature (Ta max.): 40° C (104° F)
    Storage Storage position: Upright only Ambient temperature: 10 - 30° C (50 - 86° F) Shelf life maximum, sealed: 5-Year Shelf life, opened: 2-Year reduction once opened from maximum See Safety Data Sheets (SDS) for comprehensive safety and storage information.
    Approvals Replaces Pro Steam Simulation Fluid
    Ordering Information JEM Pro-Fog Fluid, Extra Quick Dissipating, 2.5 L: P/N 97120901-00* JEM Pro-Fog Fluid, Extra Quick Dissipating, 4x 2.5 L: P/N 97120901 JEM Pro-Fog Fluid, Extra Quick Dissipating, 5 L: P/N 97120902 JEM Pro-Fog Fluid, Extra Quick Dissipating, 4x 5 L: P/N 97120902-00* JEM Pro-Fog Fluid, Extra Quick Dissipating, 9.5 L: P/N 97120900 JEM Pro-Fog Fluid, Extra Quick Dissipating, 25 L: P/N 97120903 JEM Pro-Fog Fluid, Extra Quick Dissipating, 220 L: P/N 97120904 *Minimum order quantity 4-pieces; use P/N for 4x case

Downloads

  Version Language Size Uploaded
Compliances
SIKKERHEDSDATABLAD, MARTIN EFFEKT VÆSKER
da version L, updated: Aug 21, 2018
da  224 KB Aug 21, 2018
SAFETY DATA SHEET, MARTIN EFFECT FLUIDS
au version A, updated: Aug 21, 2018
au  223 KB Aug 21, 2018
VEILIGHEIDSINFORMATIEBLAD (VIB) MARTIN‐EFFECTVLOEISTOFFEN
nl version L, updated: Aug 21, 2018
nl  230 KB Aug 21, 2018
SIKKERHETSDATABLAD, MARTIN EFFEKTVÆSKER
no version M, updated: Aug 21, 2018
no  224 KB Aug 21, 2018
Ficha de Dados de Segurança, MARTIN FLUIDOS PARA EFEITOS
pt version L, updated: Aug 21, 2018
pt  226 KB Aug 21, 2018
SCHEDA DI DATI DI SICUREZZA, Fluidi per effetti Martin
it version L, updated: Aug 21, 2018
it  224 KB Aug 21, 2018
FICHE DE DONNÉES DE SÉCURITÉ, LIQUIDES A EFFET MARTIN
fr version L, updated: Aug 21, 2018
fr  230 KB Aug 21, 2018
FICHA DE SEGURIDAD LÍQUIDOS PARA EFECTOS DE MARTIN
es version L, updated: Aug 21, 2018
es  233 KB Aug 21, 2018
SAFETY DATA SHEET, MARTIN EFFECT FLUIDS
en version L, updated: Aug 21, 2018
en  222 KB Aug 21, 2018
SICHERHEITSDATENBLATT, MARTIN‐EFFEKTFLUIDE
de version L, updated: Aug 21, 2018
de  228 KB Aug 21, 2018
Service Notes
Martin Atmospheric Effect Fluid Matrix
en version C, updated: Jun 19, 2018
en    Jun 19, 2018
Particle Size, Fluid Density and Refractive Index Values
en version B, updated: Jun 07, 2018
en    Jun 07, 2018
Martin Effect Fluid Guidelines
en version B, updated: Jun 07, 2018
en    Jun 07, 2018
Effect Fluids Cross References
en version B, updated: Aug 29, 2018
en  92.3 KB Aug 29, 2018
