Length (Head): 712 mm (28.1 in.)
Width: 536 mm (21.1 in.)
Height: 936 mm (36.9 in.)
Weight: 55.3 kg (122.0 lbs.)
Beam effects: 1 - 4 individually controllable rotating beams
Color mixing: CMY, independently variable 0 - 100%
Color temperature control: CTO, variable 6000 - 3200 K
Color wheel: 7 interchangeable dichroic filters + open, indexing, continuous rotation, random color
Rotating aerial effects: Wheel with 4 interchangeable rotating aerial effects, effect indexing, continuous rotation and shake
Iris: Variable, pulse effects
Dimming: Combined electronic and mechanical 0-100% continuous dimming, choice of four dimming curves
Mechanical shutter: Strobe effect, pulse effects, instant open and blackout
Focus: 2 m to infinity
Zoom: Motorized
Zoom-focus linking system: Automatic
Wash effect: Fade in/out
Pan: 540°
Tilt: 268°
Position correction system: Absolute position monitoring
DMX channels: 22
Setting and addressing: Control panel with backlit graphic display and jog wheel or via DMX
RDM: Implemented
16-bit control: Aerial effect indexing and rotation speed, dimmer, pan and tilt
DMX compliance: USITT DMX512-A
RDM compliance: ANSI/ESTA E1.20
Receiver: Opto-isolated RS-485
Firmware update: USB memory device or USB/DMX hardware interface over DMX link
Type: 1500 W discharge
Approved lamp: Osram HTI 1500W/60/P50 7mm Lok-it
Color temperature: 6000 K
CRI (Color rendering index): >90
Average lifetime: 750 hours
Hot restrike: Semi-hot (restrike in under 90 seconds)
Socket: PGJ50
Ballast: Electronic
Fixture identification: User-settable 12-digit ID number
Color(s): Black
Housing: Magnesium alloy, UV-resistant fiber-reinforced composite
Reflector: Glass, cold light
Protection rating: IP20
Mounting points: Eight quarter-turn locking points
Orientation: Any
Minimum distance to illuminated surfaces: 5.8 m (228.4 in.)
Minimum distance to combustible materials: 0.2 m (7.9 in.)
AC power input: Neutrik PowerCon
DMX and RDM data in/out: 5-pin locking XLR
Ethernet (Artnet II compatible, ACN-ready): Neutrik RJ-45 socket (accepts Neutrik EtherCon connectors in housing)
USB memory devices: USB host socket
Future USB options: USB device socket
AC power: 200-240 V nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch-mode
Main fuses: 16 AT (x 2)
200 V, 50 Hz: 1801 W, 9.0 A, PF 0.996
200 V, 60 Hz: 1805 W, 9.1 A, PF 0.995
208 V, 60 Hz: 1802 W, 8.8 A, PF 0.994
220 V, 50 Hz: 1788 W, 8.2 A, PF 0.994
230 V, 50 Hz: 1783 W, 7.8 A, PF 0.993
240 V, 50 Hz: 1779 W, 7.5 A, PF 0.989
240 V, 60 Hz: 1786 W, 7.5 A, PF 0.987
Cooling: Filtered forced air (temperature-regulated, low noise)
Maximum ambient temperature (Ta max.): 40° C (104° F)
Maximum surface temperature, steady state, Ta=40° C: 170° C (338° F)
Total heat dissipation (calculated, +/- 10% at 200 V, 60 Hz): 6160 BTU/hr.
EU safety: EN 60598-1, EN 60598-2-17
EU EMC: EN 55 015, EN 55 103-1, EN 61 547
US safety (pending): ANSI/UL 1573
Canadian safety (pending): CAN/CSA E60598-1, CAN/CSA E598-2-17
Lamp (installed): P/N 97010348
Two Omega clamp attachment brackets with 1/4-turn fasteners: P/N 91602001
User manual
Power cable, 12 AWG, SJT, with Neutrik PowerCon NAC3FCA input connector, 3 m: P/N 11541503
Neutrik PowerCon NAC3FCA power input connector, cable mount, blue: P/N 05342804
Omega clamp attachment bracket with 1/4-turn fasteners: P/N 91602001
T-shaped omega clamp attachment bracket with 1/4-turn fasteners: P/N 91602008
G-clamp (suspension with yoke vertically downwards only): P/N 91602003
Quick-trigger clamp (suspension with yoke vertically downwards only): P/N 91602007
Super Truss 20.5" mounting plate with half-couplers: P/N 91602014
Swing-wing truss mounting plate with half-couplers: P/N 91602010
Safety cable, safe working load 70 kg: P/N 91604004
Flightcase for 1 x MAC III™: P/N 91510080
Half-coupler (tube) clamp: P/N 91602005
Martin USB Duo™ DMX Interface Box: P/N 90703010
Martin RDM 5.5 Splitter™: P/N 90758150
Osram HTI 1500W/60/P50 7mm Lok-it lamp: P/N 97010348
Base air filter, short: P/N 20800220
Base air filter, long: P/N 20800230
Main fuse (16 AT): P/N 05020047
Quadray™ Module for MAC III AirFX™: P/N 91614042
In cardboard carton:
Shipping dimensions (LxWxH): 530 x 640 x 1060 mm (20.9 x 25.2 x 41.8 in.)
Shipping weight: 64 kg (141.1 lbs.)
Quantity on pallet: Four products in single layer
Pallet dimensions (LxWxH): 1200 x 1000 x 1320 mm (47.3 x 39.4 x 52.0 in.)
Pallet volume: 1.9 m3
Pallet weight (incl. pallet): 275 kg (606.3 lbs.)
In flightcase:
Shipping dimensions (LxWxH): 970 x 600 x 930 mm (38.2 x 23.7 x 36.7 in.)
