• Physical Length: 472 mm (18.6 in.) base 566 mm (22.3 in.) head Largura: 473 mm (18.6 in.) 335 mm (13.2 in.) base Altura: 732 mm (28.8 in.) head straight up 749 mm (29.5 in.) maximum Peso: 33 kg (72.8 lbs.) Minimum center-to-center distance in side-by-side installation: 650 mm (25.6 in.)
  Dynamic Effects Color mixing: CMY, independently variable 0 - 100% Zoom: Motorized Color temperature control: CTO, variable 6000 - 3200 K Mechanical dimmer/shutter: 0 - 100% continuous dimming, variable & random strobe & pulse effects, instant open & blackout Dimming options: Choice of four dimming curves Pan: 540° Tilt: 268° Position correction system: Absolute position monitoring Focus: Range varies with zoom angle, from 2 m / 6 m to infinity (approx.)
  Control and Programming Setting and addressing: Control panel with backlit graphic display and jog wheel or via DMX 16-bit control: Dimmer, pan, tilt DMX channels: 18/24 Receiver: Opto-isolated RS-485 DMX compliance: USITT DMX512-A RDM compliance: ANSI/ESTA E1.20 Firmware update: USB memory device or USB/DMX hardware interface over DMX link
  Optics Zoom range: 13.5° - 59° (1:5) Color temperature: 3,200 – 6,000 K Saídas: 33,000 lm
  Photometric Data

  * All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.

  Lamp Type: 1000 W short-arc discharge CRI (Color rendering index): >85 Average lifetime: 750 hours Socket: PGJX36 Ballast: Electronic Approved lamps: Osram Lok-it! 1000/PS Brilliant, Osram Lok-it! 1000W/PS VS1, Philips MSR Gold MiniFastFit 1000W
  Service Utilities Fixture identification: User-settable fixture ID number
  Construction Housing: UV-resistant fiber-reinforced composite Cor: Black Reflector: Glass, cold light Protection rating: IP20
  Installation Mounting points: Eight quarter-turn locking points Orientation: Any Minimum distance to combustible materials: 0.3 m (1.0 ft.) Minimum distance to illuminated surfaces: 3.4 m (11.2 ft.)
  Connections AC power input: Neutrik PowerCon Power Connector: Power Connector PowerCON Female : P/N 91611794 DMX and RDM data in/out: 5-pin locking XLR USB memory devices: USB host socket
• Electrical

  AC power: 120-240 V AC nominal, 50/60 Hz
  Power supply unit: Auto-ranging electronic switch mode
  Typical half-cycle RMS inrush current at 230 V, 50 Hz: 16.2 A
  Power Factor: 0.99 @ 120 V /208 V / 230 V / 240 V
  Typical current draw: 10.3 A @ 120 V , 5.8 A @ 208 V , 5.2 A @ 230 V , 5.0 A @ 240 V *
  Power Consumption
  Typical: 1225 W *
  * Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
  Typical: full output white, no effects moving, regulated fan speed.



  Thermal Cooling: Filtered forced air (temperature-regulated, low noise) Total heat dissipation (calculated, +/- 10% at 120 V, 60 Hz): 4180 BTU/hr Maximum ambient temperature (Ta max.): 40° C (104° F) Minimum ambient temperature (Ta min.): 5° C (41° F) Maximum surface temperature, steady state, at 40° C ambient: 150° C (302° F)
  Environmental RoHS: Compliant REACH: Compliant WEEE: Compliant Proposition 65: Compliant Efficacy (max output): 28 lm/w LWR*: 1,000 lm/kg (453 lm/lb)

  LWR = Lumen-to-Weight Ratio

  Approvals EU safety: EN 60598-2-17 (EN 60598-1), EN 62471 EU EMC: EN 55015, EN 55103-1, EN 55103-2, EN 61547 US safety: UL 1573 (pending) US EMC: FCC Part 15 Class A Canadian safety: CSA E598-2-17 (CSA E60598-1) (pending) Canadian EMC: ICES-003 Class A Australia/NZ: C-TICK N4241
  Included Items Lamp (installed): P/N 97010346 Two Omega clamp attachment brackets with 1/4-turn fasteners: P/N 91602001 Safety and installation manual: P/N 35000258
  Related Items Martin Companion Cable: P/N 91616091 Martin Companion Software Suite (including firmware uploader):

  Free download from www.martin.com

  Accessories Power Input Cables:

  Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 1.5 m (4.9 ft.): P/N 91611800
  Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 1.5 m (4.9 ft.): P/N 91610177
  Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 5.0 m (16.4 ft.): P/N 91611801
  Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 5.0 m (16.4 ft.): P/N 91610178
  (H07RN-F are European approved cables, SJOOW are US approved cables)

  Power connectors:

  Power Connector PowerCON Female : P/N 91611794

  PC Lens Kit for MAC Viper™ Wash: P/N 91614050 T-shaped omega clamp attachment bracket with 1/4-turn fasteners: P/N 91602008 Half-coupler (tube) clamp: P/N 91602005 G-clamp (suspension with yoke vertically downwards only): P/N 91602003 Quick-trigger clamp (suspension with yoke vertically downwards only): P/N 91602007 Omega clamp attachment bracket with 1/4-turn fasteners: P/N 91602001 Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006 Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007 Flightcase for 2 x MAC Viper: P/N 91510180
  Spare Parts Osram HTI 1000/PS Lok-it lamp: P/N 97010346 Air filter, head, MAC Viper (sold in multiples of 12): P/N 20800270
  Ordering Information MAC Viper™ Wash in cardboard box: P/N 90233050 MAC Viper™ Wash in double flightcase: P/N 90233060
  Shipping Information In cardboard carton:

  Shipping dimensions (LxWxH): 580 x 450 x 870 mm (22.9 x 17.8 x 34.3 in.)
  Shipping weight: 39 kg (86.0 lbs.)
  Quantity on pallet: 8 fixtures
  Pallet dimensions (LxWxH): 1200 x 1000 x 1860 mm (47.3 x 39.4 x 73.3 in.)
  Pallet weight (incl. pallet): 334 kg (736.4 lbs.)

  In double flightcase:

  Shipping dimensions (LxWxH): 1200 x 580 x 850 mm (47.3 x 22.9 x 33.5 in.)
  Shipping weight: 70 kg (154.4 lbs.)
  Quantity on pallet: 4 fixtures
  Pallet dimensions (LxWxH): 1200 x 1220 x 1010 mm (47.3 x 48.1 x 39.8 in.)
  Pallet weight (incl. pallet): 302 kg (665.8 lbs.)

•
