Cyclo IP65 Series
Tidak diproduksi

Cyclo IP65 Series
Gambar Lebih Besar

The Cyclo IP65 offers a competitive solution for dynamic outdoor illumination of facades, structures and bridges, with a slim linear design based on RGB and white fluorescent T5 tubes.

Fitur

  • T5 fluorescent tubes, available in 28 W (all versions) or 54 W (3 tube version only)
  • Choice of 2, 3 or 4 tube versions
  • Long lamp life (20 000 hrs)
  • RGB + W color mixing, variable color temperature
  • Impact resistant clear polycarbonate cover
  • 0-100% intensity control
  • DMX or analog versions
  • Weatherproof rating: IP65

Keterangan Lebih Lanjut

Construction Housing: Polyester-reinforced composite Front cover: Impact-resistant polycarbonate Color: Cream Protection rating: IP65
Installation Orientation: Downlight or wall mount Minimum free space: 25 mm Mounting points: Surface mount, wire suspension, 90° tilt mounting bracket (available as accessory)
Connections Power cable entry: IP68 cable gland Power connection: Quick connectors Data cable entry: IP68 cable gland Data connection: Terminal block (DMX models), quick connectors (analog models)
Electrical AC power: 198-240 V, 50/60 Hz
Thermal Maximum ambient temperature (Ta max.): 40° C Minimum ambient temperature: -20° C Cooling: Convection
Approvals EU EMC: EN 55015, EN 60555-3 EU safety: EN 60598-1, EN 60598-2-1
CE ETL C US Intertek

Unduhan

Specifications
  Versi Bahasa Ukuran Diunggah
file type icon FiberSource B150, RGB Laser 1 6, Cyclo IP65 Series- Specifications
en versi A, diperbarui: Mei 2018
A  en  11 KB Mei 2018
file type icon Cyclo IP65 Series- Specifiche
it versi A, diperbarui: Mei 2018
A  it  112 KB Mei 2018
Photometric Data
en versi A, diperbarui: Mei 2018
A   en    Mei 2018
file type icon Cyclo IP65 Series- Specifications
en versi B, diperbarui: Mei 2018
B  en  19,6 KB Mei 2018
file type icon Jem Glaciator, FiberSource B150, Cyclo IP65 Series- Specifications
en versi B, diperbarui: Okt 2020
B  en  37,8 KB Okt 2020
file type icon Jem ZR12 AL, MAC 550, Mania PR1, Mania DC3, FiberSource CMY150, Cyclo 04 Wallwasher, Cyclo IP65 Series, MAC 700 Profile, Jem ZR12 DMX, Mania EF1i- Specifiche
it versi A, diperbarui: Okt 2020
A  it  32,5 KB Okt 2020
Manuals
  Versi Bahasa Ukuran Diunggah
file type icon Cyclo IP65 Series- Bedienungsanleitung
de versi A, diperbarui: Mei 2018
A  de  575 KB Mei 2018
file type icon Cyclo IP65 Series - User manual
en versi C, diperbarui: Mei 2018
C  en  553 KB Mei 2018
file type icon Cyclo IP65 Series- Manuale d´uso
it versi A, diperbarui: Mei 2018
A  it  674 KB Mei 2018
Correction: cable gland illustration
en versi A, diperbarui: Mei 2018
A   en    Mei 2018
Illustrations
  Versi Bahasa Ukuran Diunggah
file type icon Cyclo IP65 02-03 Wall Mount Bracket Dimensons (PDF)
en versi A, diperbarui: Mei 2018
A  en  121 KB Mei 2018
file type icon Cyclo IP65 02-03 Wall Mount Bracket Dimensons (DXF)
en versi A, diperbarui: Mei 2018
A  en  210 KB Mei 2018
file type icon Cyclo IP65 Series Dimensions (PDF)
en versi A, diperbarui: Mei 2018
A  en  52 KB Mei 2018
file type icon Cyclo IP65 Series Dimensions (DXF)
en versi A, diperbarui: Mei 2018
A  en  155 KB Mei 2018
file type icon Cyclo IP65 03-04 Wall Mount Bracket Dimensions (PDF)
en versi A, diperbarui: Mei 2018
A  en  101 KB Mei 2018
file type icon Cyclo IP65 03-04 Wall Mount Bracket Dimensions (DXF)
en versi A, diperbarui: Mei 2018
A  en  153 KB Mei 2018
Compliances
  Versi Bahasa Ukuran Diunggah
file type icon EU Declaration Of Conformity, EMC
en versi A, diperbarui: Mei 2018
A  en  311 KB Mei 2018
file type icon Cyclo IP65 Series- EU Declaration of Conformity, LVD
en versi A, diperbarui: Mei 2018
A  en  161 KB Mei 2018
file type icon Mania PR1, Mania DC3, Cyclo 04 Wallwasher, Cyclo Directional, Cyclo IP65 Series, Mania PR2- EU Declaration of Conformity, LVD
en versi A, diperbarui: Mei 2018
A  en  435 KB Mei 2018
file type icon ETL Authorization To Mark, Cyclo O3 DMX IP65
en versi A, diperbarui: Mei 2018
A  en  52,5 KB Mei 2018
file type icon EU Declaration of Conformity, EMC
en versi A, diperbarui: Mei 2018
A  en  45,8 KB Mei 2018
Hints and Tips
  Versi Bahasa Ukuran Diunggah
Installing 54 Watt Tubes Will Damage a 28 Watt Cyclo
en versi A, diperbarui: Mei 2018
A   en    Mei 2018
Optimizing Cyclo Tube Lifetimes
en versi A, diperbarui: Mei 2018
A   en    Mei 2018
Running Cyclos at Very Low Ambient Temperatures
en versi A, diperbarui: Mei 2018
A   en    Mei 2018
