Length (Head): 712 mm
Width: 536 mm
Height: 936 mm
Weight: 56.5 kg
Color mixing: CMY, independently variable 0 - 100%
Color temperature control: CTO, variable 6000 - 3200 K
Color wheel: 7 interchangeable dichroic filters + open, indexing, continuous rotation, random color
Rotating gobo wheel: Rotating gobo wheel with 5 interchangeable rotating gobos + open, gobo indexing, continuous rotation and shake
Framing: Continuously rotatable framing module with 4 individually controllable blades
Gobo animation: Interchangeable animation wheel, indexing, continuous rotation with variable angle, speed and direction
Beam effects: Interchangeable frost filter (or rotating interchangeable prism)
Iris: 0 - 100%, pulse effects
Dimming: Combined electronic and mechanical 0-100% continuous dimming, choice of four dimming curves
Mechanical shutter: Strobe effect 2 - 10 Hz, pulse effects, instant open and blackout
Focus: 2 m to infinity
Zoom: 11.5° - 55° (cut-off angle)
Zoom-focus linking system: 3-zone
Pan: 540°
Tilt: 268°
Position correction system: Absolute position monitoring
DMX channels: 33/40
Setting and addressing: Control panel with backlit graphic display and jog wheel or via DMX
RDM: Implemented
16-bit control: Dimmer, gobo indexing (gobo wheel 1), frame rotation, focus, zoom, pan and tilt
DMX compliance: USITT DMX512-A
RDM compliance: ANSI/ESTA E1.20
Receiver: Opto-isolated RS-485
Firmware update: USB memory device or USB/DMX hardware interface over DMX link
Type: 1500 W short-arc discharge
Fitted as standard: Osram HTI 1500W/60/P50 Lok-it
Color temperature: 6000 K
CRI (Color rendering index): >85
Average lifetime: 750 hours
Hot restrike: Semi-hot (restrike in under 90 seconds)
Socket: PGJ50
Ballast: Electronic
Fixture identification: User-settable 12-digit ID number
Color(s): Black
Housing: Magnesium alloy, UV-resistant fiber-reinforced composite
Reflector: Glass, cold light
Protection rating: IP20
Size: E
Approved material: Borosilicate 3.3 or better with dichroic or heavy matted aluminum coating (metal gobos not approved)
Outside diameter: 37.5 mm +0/- 0.2 mm
Maximum image diameter: 30 mm +/- 0.4 mm
Maximum thickness: 1.1 mm +/- 0.1 mm
Outside diameter: 133.9 mm +/- 0.1 mm
Image outer diameter: 130 mm
Image inner diameter: 32 mm
Thickness: 1.1 mm +/- 0.1 mm
Construction: Borofloat or better with dichroic or enhanced aluminum coating
Mounting points: Eight quarter-turn locking points
Orientation: Any
Minimum distance to illuminated surfaces: 2.5 m
Minimum distance to combustible materials: 0.2 m
AC power input: Neutrik PowerCon connector with 3 m cable tail
DMX and RDM data in/out: 5-pin locking XLR
Ethernet (Artnet II compatible, ACN-ready): Neutrik RJ-45 socket (accepts Neutrik EtherCon connectors in housing)
USB memory devices: USB host socket
Future USB options: USB device socket
AC power: 200-240 V nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch-mode
Main fuses: 16 AT (x 2)
200 V, 50 Hz: 1801 W, 9.0 A, PF 0.996
200 V, 60 Hz: 1805 W, 9.1 A, PF 0.995
208 V, 60 Hz: 1802 W, 8.8 A, PF 0.994
220 V, 50 Hz: 1788 W, 8.2 A, PF 0.994
230 V, 50 Hz: 1783 W, 7.8 A, PF 0.993
240 V, 50 Hz: 1779 W, 7.5 A, PF 0.989
240 V, 60 Hz: 1786 W, 7.5 A, PF 0.987
Cooling: Filtered forced air (temperature-regulated, low noise)
Maximum ambient temperature (Ta max.): 40° C
Maximum surface temperature, steady state, Ta=40° C: 170° C
Total heat dissipation (calculated, +/- 10% at 200 V, 60 Hz): 6160 BTU/hr.
EU safety: EN 60598-1, EN 60598-2-17
EU EMC: EN 55 015, EN 55 103-1, EN 61 547
US safety: ANSI/UL 1573
Canadian safety: CAN/CSA E60598-1, CAN/CSA E598-2-17
Lamp (installed): 97010347
Tribal waves gobo animation wheel (installed): 62325143
Two Omega clamp attachment brackets with 1/4-turn fasteners: 91602001
User manual: 35000247
3 m power cable, 12 AWG, SJT, with PowerCon NAC3FCA power input connector: 11541503
Neutrik PowerCon NAC3FCA power input connector, cable mount, blue: 05342804
Philips MSR Gold 1500 Fastfit lamp: 97010340
MAC III Projection Module Kit (converts MAC III Performance to MAC III Profile): 91614033
Four-facet prism in holder: 62329120
Radial Waves gobo animation wheel: 91611355
Clouds Go By gobo animation wheel: 91611356
Flick It gobo animation wheel: 91611357
Omega clamp attachment bracket with 1/4-turn fasteners: 91602001
T-shaped omega clamp attachment bracket with 1/4-turn fasteners: 91602008
G-clamp (suspension with yoke vertically downwards only): 91602003
Quick-trigger clamp (suspension with yoke vertically downwards only): 91602007
Super Truss 20.5" mounting plate with half-couplers: 91602014
Swing-wing truss mounting plate with half-couplers: 91602010
Safety cable, safe working load 70 kg: 91604004
Half-coupler (tube) clamp: 91602005
