Computer running Windows 10 or 11 (64 bit only)
Intel Core i3 or better processor
4 GB RAM
250 MB available hard disk space
Display with Full HD or better resolution
Full administrator rights on PC
Gigabit Ethernet port for P3 output
Separate Ethernet port for Art-Net / sACN input (if used)
Separate Ethernet port for NDI input (if used)

Standard: NDI & NDI-HX
Resolution: Supporting all standard resolutions up to 1920x1080 (Full HD)
Framerate: Supporting frame rates up to 75fps

Real-time capture of any section (up to 1920x1080) of screen on machine on which P3-PC is installed
Capturing frame rate configurable up to 50 Hz
No direct support for third-party capture cards

Direct capture of any Hippotizer viewport when P3-PC is installed on a Hippo V4 (or newer) media server
Support for flipping image upside down

Controller pixel processing capacity: 20,736 pixels*
Controller fixture capacity: 2,000 fixtures*
Maximum workspace area: 8,847,360 pixels
Maximum active capture area: 2,073,600 pixels
System processing depth: 16 bits per color (48 bits per pixel)
System latency: 3 frames
Latency between first and last fixture: None
Scaling: Yes, global and mixed pixel pitch
Gamma Curve Control: Yes, adjustable
Image Control Parameters: Brightness, Contrast, Lowlight & Gain
Mapping: Real-time
Colour Temperature Control: Real-time
Colour Space Control: Real-time
Preview: Real-time (incoming video & mapping onto fixtures)
*See also P3 System Controller Capacity Info Note on Downloads page

Up to 256 universes of Art-Net or sACN input*
Control of intensity and colours
Control of colour temperature
Merge video input with DMX controls towards fixtures
Cross-fade or toggle between video and DMX controls
Freeze, blackout or activate testpatterns on video engine
Recall video presets (video settings, fixture positions and more)
*See also P3 System Controller Capacity Info Note on Downloads page

One universe of Art-Net, sACN or Kinesys K2 input*
Compatible with Kinesys K2/Vector, Tait Navigator and others
Control fixture or group position on video canvas
Control fixture or group rotation on video canvas
*See also P3 System Controller Capacity Info Note on Downloads page

Outputs the P3 Visualizer Protocol to compatible third-party (3D) visualizers via a standard network interface (can also communicate with third-party (3D) visualizer installed on the same machine)
Real-time transfer of pixel data, synchronization, calibration data, fixture patch and more
Compatible third-party visualizers: Capture 2025

Signal type: Gigabit Ethernet
Protocol : Proprietary Martin P3
Hot pluggable: Yes, electrically isolated at all connections
Cable type: Ethernet, shielded, Cat 5e or better
Cable length: Up to 100 m between any 2 devices, extendable with Ethernet switch
Maximum number of fixtures per daisy-chain: 50, extendable with Ethernet switch

Any standard PC running Windows 10 or 11 (64 bit only)

P3 data in/out: Gigabit Ethernet network port
EtherDMX Network (Art-Net, sACN and Kinesys K2/Vector): 100/1000Mbit Ethernet network port (or loopback on same machine)
NDI Video In: 100/1000Mbit Ethernet network port (or loopback on same machine)
Third-Party (3D) Visualizer Out: 100/1000Mbit Ethernet network port (or loopback on same machine)

Martin P3-175 System Controller: P/N MAR-90721100
Martin P3-275 System Controller: P/N MAR-90721101
