• Control/User Interface Determined by machine onto which the P3-PC System Controller software is installed
  Minimum System Requirements

  Computer running Windows 10 or 11 (64 bit only)
  Intel Core i3 or better processor
  4 GB RAM
  250 MB available hard disk space
  Display with Full HD or better resolution
  Full administrator rights on PC
  Gigabit Ethernet port for P3 output
  Separate Ethernet port for Art-Net / sACN input (if used)
  Separate Ethernet port for NDI input (if used)

  NDI Video Input

  Standard: NDI & NDI-HX
  Resolution: Supporting all standard resolutions up to 1920x1080 (Full HD)
  Framerate: Supporting frame rates up to 75fps

  Screen Capture Video Input

  Real-time capture of any section (up to 1920x1080) of screen on machine on which P3-PC is installed
  Capturing frame rate configurable up to 50 Hz
  No direct support for third-party capture cards

  Hippo Share Video Input

  Direct capture of any Hippotizer viewport when P3-PC is installed on a Hippo V4 (or newer) media server
  Support for flipping image upside down

  Video Processing

  Controller pixel processing capacity: 20,736 pixels*
  Controller fixture capacity: 2,000 fixtures*
  Maximum workspace area: 8,847,360 pixels
  Maximum active capture area: 2,073,600 pixels
  System processing depth: 16 bits per color (48 bits per pixel)
  System latency: 3 frames
  Latency between first and last fixture: None
  Scaling: Yes, global and mixed pixel pitch
  Gamma Curve Control: Yes, adjustable
  Image Control Parameters: Brightness, Contrast, Lowlight & Gain
  Mapping: Real-time
  Colour Temperature Control: Real-time
  Colour Space Control: Real-time
  Preview: Real-time (incoming video & mapping onto fixtures)
  *See also P3 System Controller Capacity Info Note on Downloads page

  DMX Controls

  Up to 256 universes of Art-Net or sACN input*
  Control of intensity and colours
  Control of colour temperature
  Merge video input with DMX controls towards fixtures
  Cross-fade or toggle between video and DMX controls
  Freeze, blackout or activate testpatterns on video engine
  Recall video presets (video settings, fixture positions and more)
  *See also P3 System Controller Capacity Info Note on Downloads page

• Motion Controls

  One universe of Art-Net, sACN or Kinesys K2 input*
  Compatible with Kinesys K2/Vector, Tait Navigator and others
  Control fixture or group position on video canvas
  Control fixture or group rotation on video canvas
  *See also P3 System Controller Capacity Info Note on Downloads page

  Visualizer Output

  Outputs the P3 Visualizer Protocol to compatible third-party (3D) visualizers via a standard network interface (can also communicate with third-party (3D) visualizer installed on the same machine)
  Real-time transfer of pixel data, synchronization, calibration data, fixture patch and more
  Compatible third-party visualizers: Capture 2025

  P3 Signal Protocol

  Signal type: Gigabit Ethernet
  Protocol : Proprietary Martin P3
  Hot pluggable: Yes, electrically isolated at all connections
  Cable type: Ethernet, shielded, Cat 5e or better
  Cable length: Up to 100 m between any 2 devices, extendable with Ethernet switch
  Maximum number of fixtures per daisy-chain: 50, extendable with Ethernet switch

  Installation

  Any standard PC running Windows 10 or 11 (64 bit only)

  Connections

  P3 data in/out: Gigabit Ethernet network port
  EtherDMX Network (Art-Net, sACN and Kinesys K2/Vector): 100/1000Mbit Ethernet network port (or loopback on same machine)
  NDI Video In: 100/1000Mbit Ethernet network port (or loopback on same machine)
  Third-Party (3D) Visualizer Out: 100/1000Mbit Ethernet network port (or loopback on same machine)

  Related Items

  Martin P3-175 System Controller: P/N MAR-90721100
  Martin P3-275 System Controller: P/N MAR-90721101

  Ordering Information Martin P3-PC System Controller: Free download from www.martin.com

•
