Control modes, direct DMX control: RGB and Basic DMX channels, direct DMX control: 3/10 Control modes, DMX via P3: P3 Intensity, P3 RGB, P3 Basic, P3 Hybrid and P3 PixelMap DMX channels, DMX via P3: 1/3/5/6/3

Diffuser/Lens Options:
Open Front
Flat Diffuser
Flat Smoked Diffuser
Dome Diffuser (supplied standard with fixture)
Dome Smoked Diffuser
Lens Array Narrow
All optical accessories are interchangeable and screw onto fixtures

Brightness control
Gamma correction and control
Color temperature control
Color space control
Calibration processing
Synchronization

LWR = Lumen-to-Weight Ratio

Magnetic Test Tool, set of 10: P/N 91610139

Hardware:
VDO Dotron™ Flange Bracket: P/N 91611803
VDO Dotron™ Half Coupler: P/N 91611802
VDO Dotron™ to VDO Sceptron™/Fatron™ Coupler: P/N 91616071
VDO Dotron™ to VDO Sceptron™/Fatron™ Pivot Coupler: P/N 91616072
VDO Dotron™ MultiRig Bar, 1000 mm: P/N 91616100
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007

Optical:
VDO Dotron™ Flat Diffuser: P/N 91611804
VDO Dotron™ Flat Smoked Diffuser: P/N 91611805
VDO Dotron™ Dome Diffuser: : P/N 91611806
VDO Dotron™ Dome Smoked Diffuser: P/N 91611807
VDO Dotron™ Lens Array Narrow: P/N 91611808

BBD input adapters:
Power + Data Input Cable, 4-pin male XLR (for P3 PowerPort 1500 or DMX PowerPort 375) to female BBD, 0.25 m (9.8 in.): P/N 91616046
Power + Data Input Cable, 5-pin male XLR (for DMX) + wire tails (for PSU) to female BBD, 0.25 m (9.8 in.): P/N 91616048
Power + Data Input Cable, 5-pin male XLR (for DMX) + 4-pin male XLR (for P3 PowerPort) to female BBD, 0.25 m (9.8 in.): P/N 91616049
Power + Data Input Cable, 5-pin male XLR (for DMX) + male Tripix type (for Martin IP66 PSU 240W) to female BBD, 0.25 m (9.8 in.):P/N 91616050

BBD output adapters:
Power + Data Output Cable, male BBD to 4-pin female XLR, 0.25 m (9.8 in.): P/N 91616047
DMX Lead-out Cable, male BBD to 5-pin female XLR, 0.25 m (9.8 in.): P/N 91616051

BBD extension cables:
Power + Data Extension Cable, Rental Type, BBD to BBD, 1 m (3.3 ft.): P/N 91616041
Power + Data Extension Cable, Rental Type, BBD to BBD, 2.5 m (8.2 ft.): P/N 91616024
Power + Data Extension Cable, Rental Type, BBD to BBD, 5 m (16.4 ft.): P/N 91616042
Power + Data Extension Cable, Rental Type, BBD to BBD, 10 m (32.8 ft.): P/N 91616043
Power + Data Extension Cable, Rental Type, BBD to BBD, 25 m (82.1 ft.): P/N 91616044
Power + Data Cable, Rental Type, 100 m (328 ft.) bulk without connectors: P/N 91616045

Connectors:
Power + Data Cable Connector, BBD, Male: P/N 91611750
Power + Data Cable Connector, BBD, Female: P/N 91611751
Blanking Caps for unused female BBD connectors, set of 10: P/N 91616052
