Width (across yoke): 410 mm (16.14 in.)
Width (base): 385 mm (15.16 in.)
Height (head forward): 516 mm (20.31 in.)
Height (maximum): 544 mm (21.42 in.)
Depth (head): 216 mm (8.50 in.)
Depth (base): 232 mm (9.13 in.)
Minimum center-to-center distance in side-by-side installation: 420 mm (17 in.)
Weight: 15.60 kg (34.39 lbs)

Beam Dimmer/Shutter: 0 - 100% continuous dimming, regular and random strobe, instant open and blackout
Beam Dimming options: Choice of four dimming curves
Beam Color Mixing: RGB(W), independently variable 0 - 100%
Beam Color Temperature Control: Variable 2,000 – 10,000 K
Beam Virtual Color wheel: 48 color presets, continuous rotation & random color
Zoom: Motorized with 1:8 zoom ratio
Pan: Motorized 540°
Tilt: Motorized 268°
Beam PixelMapping: individual RGB control of each of the 19 Beam pixels
Beam P3 Mix: Videomapping of fixture with variable crossfade between DMX control and video control
Aura Dimmer/Shutter: 0 – 100% continuous dimming, regular and random strobe, instant open and blackout
Aura Dimming options: Choice of four dimming curves
Aura Color Mixing: RGB, independently variable 0 - 100%
Aura Color Temperature Control: Variable 2,000 – 10,000 K
Aura Virtual Color wheel: 48 color presets, continuous rotation & random color
Aura PixelMapping: individual RGB control of each of the 141 Aura pixels
Aura P3 Mix: Videomapping of fixture with variable crossfade between DMX control and video control
Pre-programmed effects: Two ranges of FX on Beam, Aura or Combination; independent or synchronized/combined; featuring foreground color, background color, speed and direction control
LED Frequency control: Two LED PWM control rates

Control Protocols: DMX, RDM, Art-Net, RDM over Art-Net, sACN and Martin P3
Protocol Detection: Automatic
DMX Modes: Compact, Basic, Extended, Ludicrous & Compact Direct
DMX Channels: 17, 32, 89, 512 & 17
Multi-Universe Overflow: No
16-bit Controllable Parameters: Beam & Aura Dimming, Beam Color Mixing, Pan and Tilt
Setting and Addressing: Display Menu, RDM, RDM over Art-Net or Martin P3
Local User Interface: Backlit LCD Display with battery-powered operation
Fixture identification: User-settable ID number
DMX Compliance: USITT DMX512-A
RDM Compliance: ANSI/ESTA E1.20
Art-Net Compliance: Art-Net 1, 2, 3 and 4; including RDM over Art-Net
sACN Compliance: ANSI E1.31 - 2018
Martin P3 Compliance: P3 System Controller Software 5.1.0 or newer
DMX/RDM Transceiver: Galvanic-isolated RS-485
DMX/RDM Daisy-Chain Limit: 32 fixtures
Ethernet Transceiver: 10/100Mbit (with fail-safe bypass)
Ethernet Daisy-Chain Limit Recommendation: 50 fixtures
Firmware Update: via USB type A memory device, via DMX using Martin Companion or via Ethernet using Martin Companion / P3 System Controller

Front Lens Diameter: 255 mm (10.04 in.)
Zoom Range: 1:8
Full Zoom Range at Half Peak (Beam Angle): 6° - 40°
Full Zoom Range at Tenth Peak (Field Angle): 7° - 59°
Beam Light Source: 19 x 40 W RGBW LED
Aura Light Source: 141 x 0.3 W RGB LED
Max. Total Beam LED Engine Power: 570 W
Max. Total Aura LED Engine Power: 50 W
Minimum LED lifetime: > 50.000 hours (to > 70% luminous output)*
*Figure obtained under manufacturer's test conditions

Light Engine Luminous Output: 19,000 lumens
Fixture Luminous Output Wide: 10,500 lumens
Fixture Luminous Output Narrow: 8,500 lumens
Peak Luminous Intensity Narrow: 940,000 cd
CCT: Variable 2,000 K – 10,000 K (+/- 200 K)
CRI (Color Rendering Index): ≥ 73
CQS (Color Quality Scale): ≥ 85
TM-30 Rf (IES TM-30-15 Fidelity Index): ≥ 77
TM-30 Rg (IES TM-30-15 Gamut Index): ≥ 117
TLCI (Television Lighting Consistency Index): ≥ 61
Beam LED Refresh Rate: 1,200 Hz and 19,200 Hz mode (DMX controllable)
Aura LED Refresh Rate: 1,200 Hz and 4,004 Hz mode (DMX controllable)
Binning: Tight color and flux binning
Calibration: Full Gamut Color Calibration of Beam and Aura
Color Modes: Direct Color Mode, Extended Gamut Mode and Calibrated Color Mode
* All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient
* All Photometric Data measured at 6500 K white

AC mains power in/thru: Neutrik powerCON TRUE1
DMX and RDM data in/thru: Neutrik 5-pin locking XLR
Ethernet (Art-Net, sACN and Martin P3) in/thru, including fail-safe bypass: Neutrik etherCON
Firmware from flash memory: USB 2.0 type A port

AC power: 100-240 V AC nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch mode
Typical half-cycle RMS inrush current at 230 V, 50 Hz: 15.9 A
Typical earth-leakage current: 0.36 mA
Power Factor: 0.99 @ 100 V / 120 V , 0.97 @ 208 V / 230 V / 240 V
Max current draw: 6.4 A @ 100 V / 120 V , 2.8 A @ 208 V / 230 V / 240 V
Typical current draw: 5.0 A @ 100 V , 4.1 A @ 120 V , 2.4 A @ 208 V , 2.2 A @ 230 V , 2.1 A @ 240 V *
Power Consumption
Maximum: 560 W
Typical: 500 W *
Idle: 81 W *
Hibernation: 37 W *
* Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Typical: full output white, no effects moving, regulated fan speed.
Idle: no output, no effects moving, regulated fan speed.
Hibernation: no output, motors de-energized, fans stopped, wake-up procedure to re-use fixture.

LWR = Lumen-to-Weight Ratio

Two omega brackets with 1/4 turn fasteners for rigging clamp attachment
Multi-Language Safety and Installation Manual

Optical
MAC Aura PXL SoftLens: P/N MAR-91614062HU

Transport and Storage
Flightcase for 3 x MAC Aura PXL: P/N 91515052
Additional SiP Foam Flightcase Insert for MAC Aura PXL: P/N 91611860HU

Consumables
CR123A 3-volt lithium battery: P/N 05801011

Power Input Cables
Power Input Cable, H07RN-F, 2.5 mm2, bare ends to TRUE1 NAC3FX-W TOP (female), 1.5 m (4.9 ft.) P/N 91611797
Power Input Cable, SJOOW, 12 AWG, bare ends to TRUE1 NAC3FX-W TOP (female), 1.5 m (4.9 ft.) P/N 91610173

Power Linking Cables
Power relay cable, H07RN-F, 2.5 mm2, TRUE1 to TRUE1, 2.5 m (8.2 ft.): P/N 91611796
Power relay cable, SJOOW, 12 AWG, TRUE1 to TRUE1, 2.5 m (8.2 ft.): P/N 91610172

Power Connectors
Cable Connector, Neutrik powerCON TRUE1 TOP Female: P/N 91611789HU
Cable Connector, Neutrik PowerCON TRUE1 TOP Male: P/N 91611788HU

Installation Hardware
G-clamp (suspension with fixture hanging vertically downwards only): P/N 91602003
Half-coupler Clamp: P/N 91602005
Quick Trigger Clamp (suspension with fixture hanging vertically downwards only): P/N 91602007
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007

Beam Control
MAC Aura PXL Top Hat: P/N City Theatrical 2786
MAC Aura PXL Hexcel Louver: P/N City Theatrical 2787
MAC Aura PXL Concentric Ring: P/N City Theatrical 2788
MAC Aura PXL Beam Control Accessory Mount Kit: P/N City Theatrical 27880001
