Length:
452 mm (17.8 in.)
Width:
431 mm (17.0 in.) across yoke
Height:
511 mm (20.1 in.) head straight up
581 mm (22.9 in.) maximum
Weight:
21 kg (46.3 lbs.)
Pre-programmed effects:
Range of synchronized and independent color, intensity, beam twister and zone effects
Color mixing:
RGBW
Beam effects:
Beam twister, light and color morphing, color spin
'Color wheel' effect:
36 solid colors plus white, variable-speed 'color wheel rotation' effect and random color
Color ring effects:
36 split ring colors with variable-speed color wheel rotation effects
Shutter effect:
Electronic, with variable speed regular and random strobe
Color temperature control:
Variable 2000 - 10,000 K
Electronic dimming:
Four dimming curve options
Zoom:
Motorized
Pan:
540°
Tilt:
270°
Pan and tilt speed:
Adjustable via onboard control panel and DMX
Control systems:
DMX
Control resolution:
8-bit, with 16-bit control of pan, tilt, dimming and lens rotation
DMX channels:
33/17
DMX compliance:
USITT DMX512-A
RDM compliance:
ANSI/ESTA E1.20
Control options:
Independent control of color ring/beam zones
Macro programs selectable via DMX:
Range of synchronized and independent color, intensity, beam twister and zone effects
RDM:
Implemented
Setting and addressing:
Control panel with backlit graphic display
Transceiver:
RS-485
Fixture software update:
USB memory device or USB/DMX hardware interface over DMX link
Zoom range:
11–53° (1:5)
Light source:
50 x 15 W RGBW LEDs
Minimum LED lifetime:
50,000 hours (to >70% luminous output)*
LED refresh rate:
Beam 3000 Hz, Aura 3000 Hz
Output:
16,000 lm
Color Modes:
Extended Mode and Calibrated Mode
Binning:
Tight color and flux binning
Calibration:
Full Gamut Color Calibration
*Figure obtained under manufacturer´s test conditions
Housing:
High-impact flame-retardant thermoplastic
Color:
Black
Protection rating:
IP20
Mounting points:
2 pairs of quarter-turn locks
Location:
Indoor use only, must be fastened to surface or structure
Orientation:
Any
Minimum distance to combustible materials:
0.2 m
Minimum distance to illuminated surfaces:
2.0 m
AC power input:
Neutrik PowerCon
DMX and RDM data in/out:
5-pin locking XLR
AC power:
120-240 V nominal, 50/60 Hz
Power supply unit:
Auto-ranging electronic switch mode
Typical half-cycle RMS inrush current:
10.3 A
Typical power consumption, all effects static, zero light output:
Approx. 50 W
Maximum total power consumption:
1020 W
120 V, 60 Hz:
7.4 A, 880 W, PF 0.999
208 V, 60 Hz:
4.2 A, 860 W, PF 0.995
230 V, 50 Hz:
3.8 A, 856 W, PF 0.993
240 V, 50 Hz:
3.7 A, 858 W, PF 0.992
Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%.
Cooling:
Forced air (temperature-regulated, low noise, user-definable levels)
Total heat dissipation (calculated, +/- 10%):
3480 BTU/hr.
Maximum ambient temperature (Ta max.):
40° C
Minimum ambient temperature (Ta min.):
5° C
EU safety:
EN 60598-2-17 (EN 60598-1), EN 62471
EU EMC:
EN 55015, EN 55032, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547
US safety:
UL 1573
US EMC:
FCC Part 15 Class A
Canadian safety:
CSA C22.2 No. E598-2-17 (CSA E60598-1)
Canadian EMC:
ICES-003 Class A
Australia/NZ:
C-TICK N4241
2 x Omega brackets for rigging clamp attachment:
P/N 91602001
Martin™ RDM 5.5 Splitter:
P/N 90758150
Martin Companion Cable:
P/N 91616091
Martin Companion Software Suite (including firmware uploader):
Free download from www.martin.com
Power Input Cables:
Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 1.5 m (4.9 ft.): P/N 91611800
Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 1.5 m (4.9 ft.): P/N 91610177
Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 5.0 m (16.4 ft.): P/N 91611801
Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 5.0 m (16.4 ft.): P/N 91610178
(H07RN-F are European approved cables, SJOOW are US approved cables)
Power connectors:
Power Connector PowerCON Female : P/N 91611794
Soft Lens for MAC Quantum Wash™:
P/N 91611600
Installation hardware:
G-clamp (suspension with fixture hanging vertically downwards only): P/N 91602003
Quick Trigger Clamp (suspension with fixture hanging vertically downwards only): P/N 91602007
Half-coupler Clamp: P/N 91602005
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007
Flightcase for 2 x MAC Quantum™:
P/N 91510210
MAC Quantum Wash™ in cardboard box:
P/N 90240020
MAC Quantum Wash™ in 2-unit flightcase:
P/N 90240030
