Length:
701 mm (27.6 in.) head
Width:
473 mm (18.7 in.)
335 mm (13.2 in.) base
Height:
866 mm (34.1 in.) head straight up
885 mm (34.9 in.) maximum
Weight:
37.6 kg (82.9 lbs.)
Color mixing:
CMY, independently variable 0 - 100%
Color wheel:
7 interchangeable dichroic filters + open, indexing, continuous rotation, random color
Rotating aerial effects:
5 interchangeable rotating aerial effect gobos, wheel and gobo indexing, continuous rotation and shake
Static gobo wheel:
Interchangeable wheel with 7 integral gobos, wheel indexing and continuous rotation, random gobo
Iris:
0 - 100%, pulse effects
Zoom:
Motorized
Color temperature control:
CTO, variable 6000 - 3200 K
Wash effect:
Fade in/out
Mechanical dimmer/shutter:
0 - 100% continuous dimming, variable & random strobe & pulse effects, instant open & blackout
Dimming options:
Choice of four dimming curves
Pan:
540°
Tilt:
268°
Position correction system:
Absolute position monitoring
Setting, addressing, standalone programming:
Control panel with backlit graphic display and jog wheel or via DMX
16-bit control:
Dimmer, aerial effect indexing, focus, zoom, pan and tilt
DMX channels:
20/28
Receiver:
Opto-isolated RS-485
DMX compliance:
USITT DMX512-A
RDM compliance:
ANSI/ESTA E1.20
Firmware update:
USB memory device or USB/DMX hardware interface over DMX link
Zoom range:
7.5-31° (1:4)
Color temperature:
6000 K
Output:
28,500 lumens
Type:
1000 W short-arc discharge
CRI (Color rendering index):
>85
Average lifetime:
750 hours
Socket:
PGJX36
Ballast:
Electronic
Approved lamps:
Osram Lok-it! 1000/PS Brilliant, Osram Lok-it! 1000W/PS VS1, Philips MSR Gold MiniFastFit 1000W
Fixture identification:
User-settable fixture ID number
Housing:
UV-resistant fiber-reinforced composite
Color:
Black
Reflector:
Glass, cold light
Protection rating:
IP20
Size:
E27 (Size E, max. image diameter 27 mm)
Approved material:
Borosilicate 3.3 or better with dichroic or heavy matted aluminum coating (metal gobos not approved)
Outside diameter:
37.5 mm +0/- 0.2 mm (1.5 in. +0/- 0.01 in.)
Maximum image diameter:
27 mm (1.1 in.)
Maximum thickness:
1.1 mm +/- 0.1 mm (0.1 in. +/- 0.01 in.)
Mounting points:
Eight quarter-turn locking points
Orientation:
Any
Minimum distance to combustible materials:
0.3 m (1.0 ft.)
Minimum distance to illuminated surfaces:
3.4 m (11.2 ft.)
AC power input:
Neutrik PowerCon
DMX and RDM data in/out:
5-pin locking XLR
USB memory devices:
USB host socket
AC power:
120-240 V nominal, 50/60 Hz
Power supply unit:
Auto-ranging electronic switch-mode
Typical half-cycle RMS inrush current:
16.2 A
120 V, 60 Hz:
1225 W, 10.3 A, PF 0.999
208 V, 60 Hz:
1190 W, 5.8 A, PF 0.996
230 V, 50 Hz:
1186 W, 5.2 A, PF 0.994
240 V, 50 Hz:
1194 W, 5.0 A, PF 0.993
Measurements made at nominal voltage. Allow for a deviation of +/- 10%. PF = power factor.
Cooling:
Filtered forced air (temperature-regulated, low noise)
Total heat dissipation (calculated, +/- 10% at 120 V, 60 Hz):
4180 BTU/hr
Maximum ambient temperature (Ta max.):
40° C (104° F)
Minimum ambient temperature (Ta min.):
5° C (41° F)
Maximum surface temperature, steady state, at 40° C ambient:
150° C (302° F)
EU safety:
EN 60598-2-17 (EN 60598-1), EN 62471
EU EMC:
EN 55015, EN 55103-1, EN 55103-2, EN 61547
US safety:
UL 1573
US EMC:
FCC Part 15 Class A
Canadian safety:
CSA E598-2-17 (CSA E60598-1)
Canadian EMC:
ICES-003 Class A
Australia/NZ:
C-TICK N4241
Lamp (installed):
P/N 97010346
Two Omega clamp attachment brackets with 1/4-turn fasteners:
P/N 91602001
Safety and installation manual
Martin USB Duo™ DMX Interface Box:
P/N 90703010
Martin™ RDM 5.5 Splitter:
P/N 90758150
Power cable, 12 AWG, SJT, with Neutrik PowerCon NAC3FCA input connector, 3 m (9.9 ft.):
P/N 11541503
Neutrik PowerCon NAC3FCA power input connector, cable mount, blue:
P/N 05342804
T-shaped omega clamp attachment bracket with 1/4-turn fasteners:
P/N 91602008
Half-coupler (tube) clamp:
P/N 91602005
G-clamp (suspension with yoke vertically downwards only):
P/N 91602003
Quick-trigger clamp (suspension with yoke vertically downwards only):
P/N 91602007
Safety cable, safe working load 70 kg (154 lbs.):
P/N 91604004
Omega clamp attachment bracket with 1/4-turn fasteners:
P/N 91602001
Flightcase for 2 x MAC Viper:
P/N 91510180
Osram HTI 1000/PS Lok-it lamp:
P/N 97010346
Air filter, head, MAC Viper (sold in multiples of 12):
P/N 20800270
MAC Viper™ Beam Kit:
P/N 91614053
In cardboard carton:
Shipping dimensions (LxWxH): 580 x 450 x 870 mm (22.9 x 17.8 x 34.3 in.)
Shipping weight: 39 kg (86.0 lbs.)
Quantity on pallet: 8 fixtures
Pallet dimensions (LxWxH): 1200 x 1000 x 1860 mm (47.3 x 39.4 x 73.3 in.)
Pallet weight (incl. pallet): 334 kg (736.4 lbs.)
In double flightcase:
Shipping dimensions (LxWxH): 1200 x 580 x 850 mm (47.3 x 22.9 x 33.5 in.)
Shipping weight: 70 kg (154.4 lbs.)
