• 物理特性 长度: 270 mm (10.7 in.) 宽: 334 mm (13.2 in.) 高: 382 mm (15.1 in.) 重量: 13.0 kg (28.7 lbs.)
  Dynamic Effects Intensity: 0 - 100% Color mixing: RGBW
  Control and Programming Control systems: DMX, RDM Stand-alone control: Up to 20 scenes with global fade/hold times Setting, addressing, standalone programming: Control panel with OLED display DMX channels: 3-5 depending on DMX mode Receiver: RS-485 DMX compliance: USITT DMX512-A RDM compliance: ANSI/ESTA E1.20 Firmware update: Serial upload via DMX link
  Optics Light source: 16 x R, 18 x G, 16 x B, 18 x W single-color LEDs Minimum LED lifetime: 50,000 hours (to >70% luminous output)* LED manufacturer: Cree Beam Angle Options:

  No diffuser: 7.5°
  Narrow diffuser: 11.5°
  Medium diffuser: 25°
  Wide diffuser: 36°
  Very wide diffuser: 60°
  Asymmetric diffuser: 59° x 14.5°

  Binning: Tight color and flux binning Calibration: Full Gamut Color Calibration *Figure obtained under manufacturer's test conditions
  Photometric Data CRI (Color Rendering Index) : > 70 CCT: 6500 K (White LED) Total luminous output: 6500 lumens*

  * All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.

  Construction Housing: Cast aluminum 颜色: Light grey (white, black or other colors available on request) Ingress protection rating: IP66 Surface treatment: Anodized and electrostatic powder-coated Effective Projected Area (EPA): 0.1 m² including snoot Impact resistance: IK08 (with control panel display cover plate installed) Corrosion resistance: C5-M (very high corrosivity / marine, ISO 12944) Vibration resistance: 1.0g, Sinusoidal (IEC 60068-2-6)
  0,7g RMS Random (IEC 60068-2-64)
  Installation 装配: Adjustable yoke Orientation: Any Minimum distance to illuminated surfaces: 0.2 m (0.6 ft.)
  Connections Power connection: 1.8 m (5.9 ft.) cable tail without connector Power input cable type, EU models: H05RN-F 300/500V, 3 x 0.75 mm2, Ø 7 mm Power input cable type, US models: SJOW 18AWG, 300V, WL F1, Ø 8 mm Data connection: 1.8 m (5.9 ft.) open ended 5-conductor combined input + output cable tail All cable entries: IP68 cable gland
• Electrical AC power: 100 - 240 / 277 V nominal, 50/60 Hz Power supply unit: Integrated, auto-sensing multi-voltage

  功耗

  : 3 W (steady state, all LEDs at zero intensity) Typical half-cycle RMS inrush current: 10.3 A Maximum total power consumption: 185 W Surge protection: 4 KV Max earth leakage: 0.50 mA
  Typical Power and Current 100 V, 60 Hz: 1.6 A, 160 W, PF 0.99 120 V, 60 Hz: 1.35 A, 160 W, PF 0.99 230 V, 50 Hz: 0.75 A, 160 W, PF 0.94 277 V, 60 Hz: 0.65 A, 160 W, PF 0.89 Measurements made with fixture in steady state at nominal voltage, ambient temperature (Ta) 20° C (68° F), all LEDs at full intensity. Allow for a deviation of +/- 10%.
  Thermal 散热: Convection Maximum ambient temperature (Ta max.): 45° C (113° F)* Minimum ambient temperature (Ta min.): -30° C (-22° F)** Maximum surface temperature, steady state, at 40° C ambient: 55° C (131° F) Total heat dissipation (calculated, +/- 10%): 485 BTU/hr

  *Above this temperature, the fixture regulates output to protect from overheating
  **Power must be maintained below -20° C (-4° F)

  Environmental RoHS: Compliant REACH: Compliant WEEE: Compliant Proposition 65: Compliant Efficacy (max output): 41 lm/W LWR*: 500 lm/kg (224 lm/lb)

  LWR = Lumen-to-Weight Ratio

  Approvals Global CB Certification/IECEE: IEC 60598-2-5 (IEC 60598-1) EU safety: EN60598-2-5 (EN60598-1), EN62471, EN62493, EN60598-2-1 EU EMC: EN55015, EN61547, EN61000-3-2, EN6100-3-3, EN61000-4-2, EN6100-4-4, EN6100-4-5 US safety: ANSI/UL 1598 US EMC: 47 CFR Part 15 Class A Canadian safety: CSA C.22.2 No. 250 Australia/NZ: RCM India: BIS
  Included Items Cover plate for control panel
  Related Items Martin Companion Cable: P/N 91616091
  Accessories Exterior Wash 200 Series, narrow diffuser kit: P/N 91610154 Exterior Wash 200 Series, medium diffuser kit: P/N 91610153 Exterior Wash 200 Series, wide diffuser kit: P/N 91610152 Exterior Wash 200 Series, very wide diffuser kit: P/N 91610151 Exterior Wash 200 Series, asymmetric diffuser kit: P/N 91610150 Exterior Wash 200 Series, glare shield / snoot: P/N 91611745 Exterior Wash 200 Honeycomb Louvre: P/N 91611857
  Ordering Information Exterior Wash 200, 7°, EU, aluminum: P/N 90509087 Exterior Wash 200, 7°, US, aluminum: P/N 90509090
