Length: 473 mm (18.7 in.)Width: 248 mm (9.8 in.)Height: 164 mm (6.5 in.)Weight: 9.5 kg 21.0 lbs.)
Color mixing: RGBWColor selection: 32 color presetsElectronic 'shutter' effect: Strobe effect, pulse effects, instant open and blackoutPre-programmed effects: 12 pre-programmed macros with adjustable speedElectronic dimming: 0 - 100%
Control options: DMX, stand-alone, host/clientDMX channels: 44Stand-alone trigger options: Music trig, auto trigSetting and addressing: Control panel with LCD displayProtocol: USITT DMX512/1990
Light source: 10 x 10 W RGBW Cree XM-L LEDsMinimum LED lifetime: 50 000 hours (to >70% luminous output)*Beam angle: 8°
Color: BlackHousing: High-impact flame-retardant thermoplasticProtection rating: IP20
Mounting points: Two quarter-turn brackets for rigging clampsLocation: Indoor use only, must be fastened to surface or structureOrientation: Any
AC power in/thru: Neutrik PowerConDMX data in/out: 3-pin and 5-pin locking XLR
AC power: 100-240 V nominal, 50/60 HzTypical total power consumption: 130 W
Cooling: Forced air (temperature-regulated, low noise)Maximum ambient temperature (Ta max.): 40° C (104° F)Minimum ambient temperature (Ta min.): 0° C (32° F)Total heat dissipation (calculated, +/- 10%, at full intensity, full white): 450 BTU/hr.
EU safety: EN 60598-2-17 (EN 60598-1), EN 62471, EN 62493EU EMC: EN 55015, EN 55103-1, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547US safety: UL 1573US EMC: 47 CFR Part 15 Class AAustralia/NZ: C-TICK N4241
Power cable 1.5 m
Cables, 16 A, for connection to power in chainsPower input cable, 14 AWG, UL, SJT, 1.5 mm2, H05VV-F, with PowerCon input connector, 3 m (9.8 ft.): P/N 11541508Power relay cable, 14 AWG, UL, SJT, 1.5 mm2, H05VV-F, with PowerCon connectors, 1.4 m (4.6 ft.): P/N 11541509Power relay cable, 14 AWG, UL, SJT, 1.5 mm2, H05VV-F, with PowerCon connectors, 2.25 m (7.4 ft.): P/N 11541510Power relay cable, 14 AWG, UL, SJT, 1.5 mm2, H05VV-F, with PowerCon connectors, 3.25 m (10.7 ft.): P/N 11541511Power connectorsNeutrik PowerCon NAC3FCA power input connector, cable mount, blue: P/N 05342804Neutrik PowerCon NAC3FCB power output connector, cable mount, light grey: P/N 05342805Installation hardwareHalf-coupler clamp: P/N 91602005G-clamp (suspension vertically downwards only): P/N 91602003Quick-trigger clamp (suspension vertically downwards only):P/N 91602007
RUSH™ Software Uploader 1: P/N 91611399
RUSH Multibeam 2™ in cardboard box: P/N 90480030
