The MCC series (Maxedia Capture Card) are low latency capture cards used in the Maxedia PRO and Maxedia Broadcast, offering high definition in the highest quality and speed available today.
MCC Dual HD-SDI input card for Maxedia
• Low latency capture card for the Maxedia PRO and Broadcast range from Rev C and up
• SD-SDI & HD-SDI compatible (SMPTE 259M-C and SMPTE 292)
• 480i, 576i, 720P and 1080i compatible
• 25fps, 29,97fps, 30fps, 50fps, 59,94fps and 60fps
• Every input can have a different resolution and frame rate while capturing
• Auto detect of the input resolution at startup of the Maxedia software
• Uncompressed 8-bit digital video capture 4:2:2
• Cable equalization on both inputs for 270 Mbit/s - 1.485 Gbit/s signals on BNC coaxial cable
MCC Dual DVI/VGA input card for Maxedia
• Low latency capture card for the Maxedia PRO and Broadcast range from Rev C and up
• DVI-D (digital)/DVI-A (analog RGBHV) 640 x 480, up to 1920x1080 pixels
• HDMI 480i/p, 576i/p, 720P & 1080i
• Built-in EDID per input switchable between Analog and Digital (Maxedia software 4.x required)
• Every input can have a different resolution and frame rate while capturing
• Adaptive equalizer for cable lengths up to 30 meters (by using quality cable)
• DVI 1.0 and HDMI 1.3 single link compliant. No HDCP digital content protection support
• VGA-to-DVI & HDMI-to-DVI connections possible through standard adapters (not provided)
