Length:
472 mm (18.6 in.) base 566 mm (22.3 in.) head
Width:
473 mm (18.6 in.) 335 mm (13.2 in.) base
Height:
732 mm (28.8 in.) head straight up 749 mm (29.5 in.) maximum
Weight:
34.1 kg (75.2 lbs.)
Minimum center-to-center distance in side-by-side installation:
650 mm (25.6 in.)
Color mixing:
CMY, independently variable 0 - 100%
Color wheel:
7 interchangeable dichroic filters + open, indexing, continuous rotation, random color
Beam shaping:
Internal barn doors, continuously variable opening, indexed rotation
Iris:
0 - 100%, pulse effects
Zoom:
Motorized
Color temperature control:
CTO, variable 6000 - 3200 K
Mechanical dimmer/shutter:
0 - 100% continuous dimming, variable & random strobe & pulse effects, instant open & blackout
Dimming options:
Choice of four dimming curves
Pan:
540°
Tilt:
268°
Position correction system:
Absolute position monitoring
Setting and addressing:
Control panel with backlit graphic display and jog wheel or via DMX
16-bit control:
Dimmer, pan, tilt
DMX channels:
18/24
Receiver:
Opto-isolated RS-485
DMX compliance:
USITT DMX512-A
RDM compliance:
ANSI/ESTA E1.20
Firmware update:
USB memory device or USB/DMX hardware interface over DMX link
Zoom range:
13.5° - 59° (1:5)
Color temperature:
3,200 – 6,000 K
Output:
33,000 lm
* All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.
Type:
1000 W short-arc discharge
CRI (Color rendering index):
>85
Average lifetime:
750 hours
Socket:
PGJX36
Ballast:
Electronic
Approved lamps:
Osram Lok-it! 1000/PS Brilliant, Osram Lok-it! 1000W/PS VS1, Philips MSR Gold MiniFastFit 1000W
Fixture identification:
User-settable fixture ID number
Housing:
UV-resistant fiber-reinforced composite
Color:
Black
Reflector:
Glass, cold light
Protection rating:
IP20
Mounting points:
Eight quarter-turn locking points
Orientation:
Any
Minimum distance to combustible materials:
0.3 m (1.0 ft.)
Minimum distance to illuminated surfaces:
3.4 m (11.2 ft.)
AC power input:
Neutrik PowerCon
DMX and RDM data in/out:
5-pin locking XLR
USB memory devices:
USB host socket
AC power: 120-240 V AC nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch mode
Typical half-cycle RMS inrush current at 230 V, 50 Hz: 16.2 A
Power Factor: 0.99 @ 120 V / 208 V / 230 V / 240 V
Typical current draw: 10.3 A @ 120 V , 5.8 A @ 208 V , 5.2 A @ 230 V , 5.0 A @ 240 V *
Power Consumption
Typical: 1225 W *
* Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Typical: full output white, no effects moving, regulated fan speed.
Cooling:
Filtered forced air (temperature-regulated, low noise)
Total heat dissipation (calculated, +/- 10% at 120 V, 60 Hz):
4180 BTU/hr
Maximum ambient temperature (Ta max.):
40° C (104° F)
Minimum ambient temperature (Ta min.):
5° C (41° F)
Maximum surface temperature, steady state, at 40° C ambient:
150° C (302° F)
RoHS:
Compliant
REACH:
Compliant
WEEE:
Compliant
Proposition 65:
Compliant
Efficacy (max output):
28
LWR*:
967 lm/kg (438 lm/lb)
LWR = Lumen-to-Weight Ratio
EU safety:
EN 60598-2-17 (EN 60598-1), EN 62471
EU EMC:
EN 55015, EN 55103-1, EN 55103-2, EN 61547
US safety:
UL 1573 (pending)
US EMC:
FCC Part 15 Class A
Canadian safety:
CSA E598-2-17 (CSA E60598-1) (pending)
Canadian EMC:
ICES-003 Class A
Australia/NZ:
C-TICK N4241
Lamp (installed):
P/N 97010346
Two Omega clamp attachment brackets with 1/4-turn fasteners:
P/N 91602001
Safety and installation manual:
P/N 35000258
Martin Companion Cable:
P/N 91616091
Martin Companion Software Suite (including firmware uploader):
Free download from www.martin.com
Power Input Cables:
Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 1.5 m (4.9 ft.): P/N 91611800
Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 1.5 m (4.9 ft.): P/N 91610177
Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 5.0 m (16.4 ft.): P/N 91611801
Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 5.0 m (16.4 ft.): P/N 91610178
(H07RN-F are European approved cables, SJOOW are US approved cables)
Power connectors:
Power Connector PowerCON Female : P/N 91611794
PC Lens Kit for MAC Viper™ Wash:
P/N 91614050
T-shaped omega clamp attachment bracket with 1/4-turn fasteners:
P/N 91602008
Half-coupler (tube) clamp:
P/N 91602005
G-clamp (suspension with yoke vertically downwards only):
P/N 91602003
Quick-trigger clamp (suspension with yoke vertically downwards only):
P/N 91602007
Omega clamp attachment bracket with 1/4-turn fasteners:
P/N 91602001
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black:
P/N 91604006
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver:
P/N 91604007
Flightcase for 2 x MAC Viper:
P/N 91510180
Osram HTI 1000/PS Lok-it lamp:
P/N 97010346
Air filter, head, MAC Viper (sold in multiples of 12):
P/N 20800270
MAC Viper™ Wash DX in cardboard box:
P/N 90233070
MAC Viper™ Wash DX in 2-unit flightcase:
P/N 90233080
In cardboard carton:
Shipping dimensions (LxWxH): 580 x 450 x 870 mm (22.9 x 17.8 x 34.3 in.)
Shipping weight: 39 kg (86.0 lbs.)
Quantity on pallet: 8 fixtures
Pallet dimensions (LxWxH): 1200 x 1000 x 1860 mm (47.3 x 39.4 x 73.3 in.)
Pallet weight (incl. pallet): 334 kg (736.4 lbs.)
In double flightcase:
Shipping dimensions (LxWxH): 1200 x 580 x 850 mm (47.3 x 22.9 x 33.5 in.)
Shipping weight: 70 kg (154.4 lbs.)
Quantity on pallet: 4 fixtures
Pallet dimensions (LxWxH): 1200 x 1220 x 1010 mm (47.3 x 48.1 x 39.8 in.)
Pallet weight (incl. pallet): 302 kg (665.8 lbs.)
