Length: 215 mm (8.5 in.)Width: 135 mm (5.4 in.)Height: 152 mm (6.0 in.)Weight: 2 kg (11.0 lbs.)
Gobo projection: Static or rotating gobo operationFocus: Manual
Light source: 20 W LED arrayBeam angle: 17°Minimum LED lifetime*: 30 000 hours (to >70% luminous output)
Color: SilverProtection rating: IP20
Size: E24 (Size E, max. image diameter 24 mm)Recommended material: Steel or glassOutside diameter: 37.5 mm +0/-0.2 mmMaximum image diameter: 24 mmMaximum thickness: 3 mm
Mounting: Adjustable folding bracket, surface or truss mountLocation: Indoor use only, must be fastened to surface or structureOrientation: Any
AC power: IEC
AC power: 100-240 V, 50/60 HzPower consumption: 20 W
Maximum ambient temperature (Ta max.): 40° C (104° F)Minimum ambient temperature (Ta min.): 0° C (32° F)Total heat dissipation*: 70 BTU/hr.
EU safety: EN 60598-2-1 (EN 60598-1), EN 62471, EN 62493EU EMC: EN 55015, EN 55032, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547US safety: UL 122US EMC: FCC Part 15 Class ACanadian safety: CSA C22.2 No. 118-1959Canadian EMC: ICES-003 Class AAustralia/NZ: C-TICK N4241
Mounting bracketPower cable, 1.5 m, without mains plug (US model includes mains plug)
RUSH™ Software Uploader 1: P/N 91611399
RUSH Gobo Projector™ in cardboard box, EU model: P/N 90480060RUSH Gobo Projector ™ in cardboard box, US model: P/N 90480065
