* All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.

Power/data in/thru: 8-pin custom connectors
Surge Protection: 4 KV
Maximum connected 4 ft fixtures *: 42 pcs (52 m /169 ft) @ 230-277 V
Maximum total string length (cable + fixtures)*: 150 m / 328 ft
* Refer to system diagram for details on fixture run limitations.

AC power: 100-277 V AC nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch mode
Typical half-cycle RMS inrush current at 230 V, 50 Hz: 0.35 A
Typical earth-leakage current 1 ft: 0.15 mA
Typical earth-leakage current 4 ft: 0.21 mA
Power Factor 12 W / 10 W mode: 0.95 @ 100 V / 120 V / 208 V / 230 V / 240 V , 0.90 @ 277 V
Power Factor 5 W mode: 0.90 @ 100 V / 120 V / 208 V / 230 V / 240 V , 0.70 @ 277 V

Power Consumption 1 ft
Maximum: 12 W / 10 W / 5 W *
Idle: 1.54 W *

Power Consumption 4 ft
Maximum: 48 W / 40 W / 20 W *
Idle: 2.30 W *

* Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Idle: steady state, all LEDs at zero intensity.
Power Consumption: Depending on power setting mode.

^*LWR = Lumen-to-Weight Ratio

Beam control
Glare shield, EL Pro 1ft set of 4: P/N MAR-90570022
Glare shield, EL Pro, 4ft set of 4: P/N MAR-90570023
Louvre, EL Pro Quad 1ft set of 4: P/N MAR-90570024
Asymm diffuser Wide EL Pro 4ft, set of 6: P/N MAR-90570020
Asymm diffuser Narrow EL Pro 4ft, set of 6: P/N MAR-90570021

Mounting brackets
Adjustable bracket EL Pro 10 pcs: P/N MAR-90570025
Flange bracket EL Pro 10 pcs: MAR-90570026
Quick mount bracket EL Pro 10 pcs: P/N MAR-90570027

Pre-assembled PD Hybrid Power DMX cables
Power DMX Cable PD PD 0.2M: P/N MAR-91700004
Power DMX Cable PD PD 1M EU: MAR-91700005
Power DMX Cable PD PD 2.5M EU: P/N MAR-91700006
Power DMX Cable PD PD 5M EU: P/N MAR-91700007
Power DMX Cable PD PD 10M EU: P/N MAR-91700008
Power DMX Cable PD PD 0.2M US: P/N MAR-91700010
Power DMX Cable PD PD 1M US: P/N MAR-91700011
Power DMX Cable PD PD 2.5M US: P/N MAR-91700012
Power DMX Cable PD PD 5M US: P/N MAR-91700013
Power DMX Cable PD PD 10M US: P/N MAR-91700014

Bulk Hybrid Power DMX Cables and Connectors
Power DMX Cable 100M Roll EU: P/N MAR-91700009
Power DMX Cable 100M Roll US: P/N MAR-91700016
Field installable connector PD female: P/N MAR-91700017
Field installable connector PD male: P/N MAR-91700018

Junction Box, End Termination Cap, Multitool
End termination cap PD: P/N MAR-91700015
Junction Box Power DMX to PD: P/N MAR-91700019
Exterior Multitool: P/N MAR-90590025
