Length: 241 mm across yoke
Width: 241 mm across yoke
Height: 304 mm
Weight: 3.7 kg
Shutter effect: Electronic, with pulse and random effects
Electronic dimming: 0 - 100%, four dimming curve options
Pan: 540°
Tilt: 240°
Pan and tilt speed: Adjustable via onboard control panel and DMX
Control: DMX
RDM: Implemented
Control resolution: 8-bit, with 16-bit control of pan & tilt
DMX channels: 7
Setting and addressing: Control panel with backlit graphic display
Protocol: USITT DMX512-A, ANSI/ESTA E1.20 RDM
Transceiver: RS-485
Fixture software update: Via DMX with Martin™ USB Duo DMX Interface Box
Light source: Cree XP-E high power emitters
Color temperature: 6700 K
Minimum LED lifetime: 50 000 hours (to >70% luminous output)*
LED refresh rate: 1220 Hz
Color: Black or white
Housing: High-impact flame-retardant thermoplastic
Protection rating: IP20
Mounting points: One M12 threaded hole for rigging clamp
Location: Indoor use only, must be fastened to surface or structure
Orientation: Any
Minimum distance to combustible materials: 100 mm from head, no minimum distance from base
Minimum distance to illuminated surfaces: 200 mm
AC power input: Neutrik PowerCon
AC power throughput: Neutrik PowerCon
DMX data in/out: 5-pin locking XLR
AC power: 100-240 V nominal, 50/60 Hz
Maximum total power consumption: 123 W
Power supply unit: Auto-ranging electronic switch mode
Main fuse: 5 AT (slow blow)
Typical power consumption, all effects static, zero light output: <25 W
100 V, 50 Hz: 122 W, 1.3 A, PF 0.991
120 V, 60 Hz: 121 W, 1.1 A, PF 0.987
208 V, 60 Hz: 123 W, 0.7 A, PF 0.938
230 V, 50 Hz: 123 W, 0.6 A, PF 0.915
240 V, 50 Hz: 123 W, 0.6 A, PF 0.900
Cooling: Forced air (temperature-regulated, low noise, user-definable levels)
Maximum ambient temperature (Ta max.): 40° C
Minimum ambient temperature (Ta min.): 5° C
Total heat dissipation (calculated, +/- 10%): 420 BTU/hr.
EU safety: EN 60598-2-17, EN 62471
EU EMC: EN 55103-1, EN 55103-2, EN 55015, EN 61547
US safety: UL 1573
US EMC: FCC Part 15 Class A
Canadian safety: CSA E598-2-17
Canadian EMC: ICES-003 Class A
Australia/NZ: C-TICK N4241
M12 bolt suitable for use with Martin rigging clamps:
User manual: 35000246
3 m power cable, 12 AWG, SJT, with PowerCon NAC3FCA power input connector: TBA
Neutrik PowerCon NAC3FCA power input connector, cable mount, blue: 05342804
Neutrik PowerCon NAC3FCB power output connector, cable mount, light grey: 05342805
Set of eight narrow diffusers for MAC 101: 91616023
Set of eight wide diffusers for MAC 101: 91616018
Set of 4 top hats for MAC 101: 91611358
Set of 5 quick-mount surface mounting brackets for MAC 101: 91606017
G-clamp: 91602003
Quick trigger clamp: 91602007
Safety cable, safe working load 50 kg: 91604003
8-unit flightcase for MAC 101™: 91515010
Half-coupler (tube) clamp: 91602005
Martin USB Duo™ DMX Interface Box: 90703010
Martin RDM 5.5 Splitter™: 90758150
MAC 101 CLD™ in cardboard box: 90231670
MAC 101 CLD™ in 8-unit flightcase: 90231660
