Length:
302 mm (11.9 in.) across yoke
Width:
302 mm (11.9 in.) across yoke
Height:
360 mm (14.2 in.), head straight up
Weight:
5.6 kg (12.4 lbs.) without accessories
Beam color mixing:
RGBW
Aura (secondary lens array illumination) color mixing:
RGB
Beam color temperature control:
CTO, variable 10 000 - 2500 K
Beam and aura electronic 'color wheel' effect:
33 LEE-referenced colors plus white, variable-speed color-wheel rotation effect and random color
Beam and aura independent shutter effects:
Electronic, with regular and random pulse, burst and strobe effects
Pre-programmed effects:
Range of synchronized and independent beam and aura FX, different FX can be combined
Electronic dimming:
Independent beam and aura, four dimming curve options
Pan:
540°
Tilt:
232°
Pan and tilt speed:
Adjustable via onboard control panel and DMX
Control resolution:
8-bit, with 16-bit control of pan & tilt
Control options:
Independent control of beam (primary output) and aura (secondary lens array illumination)
Setting and addressing:
Control panel with backlit graphic display
Macro programs selectable via DMX:
Synchronized beam and aura effects
Control:
DMX
RDM:
Implemented
DMX channels:
14/25
DMX compliance:
USITT DMX512-A
RDM compliance:
ANSI/ESTA E1.20
Transceiver:
RS-485
Fixture software update:
Via DMX with Martin™ USB Duo DMX Interface Box
Zoom range:
11° - 58°
Peak angle:
One-tenth
Light source:
19x 10W RGBW LED Array System
Minimum LED lifetime:
50,000 hours (to >70% luminous output)*
LED refresh rate:
Beam 1220 Hz, Aura 4395 Hz
Color Modes:
Calibrated Mode and Raw Mode
Binning:
Tight color and flux binning
Calibration:
Full Gamut Color Calibration
*Figure obtained under manufacturer´s test conditions
Total output:
3850 lumens (zoom at maximum)
* All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.
Housing:
High-impact flame-retardant thermoplastic
Color:
Black
Protection rating:
IP20
Mounting points:
One M12 threaded hole for rigging clamp
Location:
Indoor use only, must be fastened to surface or structure
Orientation:
Any
Minimum distance to combustible materials:
100 mm (4.0 in.)
Minimum distance to illuminated surfaces:
200 mm (7.9 in.)
AC power input:
Neutrik PowerCon
AC power throughput:
Neutrik PowerCon
DMX and RDM data in/out:
5-pin locking XLR
AC power:
100-240 V nominal, 50/60 Hz
Power supply unit:
Auto-ranging electronic switch mode
Main fuse:
5 AT (slow blow)
Typical power consumption, all effects static, zero light output:
<15 W
Maximum total power consumption:
260 W
100 V, 60 Hz:
236 W, 2.4 A, PF 0.994
120 V, 60 Hz:
234 W, 2.0 A, PF 0.992
208 V, 60 Hz:
229 W, 1.2 A, PF 0.970
230 V, 50 Hz:
228 W, 1.1 A, PF 0.959
240 V, 50 Hz:
228 W, 1.0 A, PF 0.953
Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%.
Cooling:
Forced air (temperature-regulated, low noise, user-definable levels)
Maximum ambient temperature (Ta max.):
40° C (104° F)
Minimum ambient temperature (Ta min.):
5° C (41° F)
Total heat dissipation (calculated, +/- 10%):
880 BTU/hr.
RoHS:
Compliant
REACH:
Compliant
WEEE:
Compliant
Proposition 65:
Compliant
EU safety:
EN 60598-2-17 (EN 60598-1), EN 62471
EU EMC:
EN 55103-1, EN 55103-2, EN 55015, EN 61547
US safety:
UL 1573
US EMC:
FCC Part 15 Class A
Canadian safety:
CSA E598-2-17 (CSA E60598-1)
Canadian EMC:
ICES-003 Class A
Australia/NZ:
C-TICK N4241
User manual:
P/N 35000254
M12 bolt suitable for use with Martin rigging clamps
Martin Companion Cable:
P/N 91616091
Martin Companion Software Suite (including firmware uploader):
Free download from www.martin.com
Power connectors:
Power Connector PowerCON Male: P/N 91611795
Power Connector PowerCON Female: P/N 91611794
Cables, 16 A, for connection to power in chains:
Power relay cable 3 x 2.5 mm2, H07RN-F POWCON-POWCON 1.2 m (3.9 ft.): P/N 91611798
Power relay cable 3 x 14 AWG, SJOOW POWCON-POWCON 1.2m (3.9 ft.): P/N 91610175
Power relay cable 3 x 2.5 mm2, H07RN-F POWCON-POWCON 2.5m (8.2 ft.): P/N 91611799
Power relay cable 3 x 14 AWG, SJOOW POWCON-POWCON 2.5m (8.2 ft.): P/N 91610176
Cables, 16 A, for power input:
Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 1.5 m (4.9 ft.): P/N 91611800
Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 1.5 m (4.9 ft.): P/N 91610177
Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 5.0 m (16.4 ft.): P/N 91611801
Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 5.0 m (16.4 ft.): P/N 91610178
Set of 5 quick-mount surface mounting brackets:
P/N 91606017
6-unit flightcase for MAC Aura:
P/N 91515020
MAC Aura / Aura XB Soft Lens Kit:
P/N 91611730
(H07RN-F are European approved cables,SJOOW are US approved cables)
Installation hardware:
G-clamp (suspension with fixture hanging vertically downwards only): P/N 91602003
Quick Trigger Clamp (suspension with fixture hanging vertically downwards only): P/N 91602007
Half-coupler Clamp: P/N 91602005
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007
MAC Aura™ in cardboard box:
P/N 90232000
MAC Aura™ in 6-unit flightcase:
P/N 90232010
MAC Aura™, white finish, in cardboard box*
*Available by special order - please contact your Martin™ supplier for details
