• Physical Length: 452 mm (17.8 in.) Width: 480 mm (18.9 in.) across yoke Height:

  740 mm (29.2 in.) maximum
  731 mm (28.8 in.) head straight up

  Weight: 31 kg (68.4 lbs.) Minimum center-to-center distance in side-by-side installation: 700 mm (27.6 in.)
  Dynamic Effects Pre-programmed effects: Two ranges of FX, independent or synchronized/combined Color mixing: CMY, independently variable 0 - 100% Color wheel: 6 x interchangeable dichroic filters + open, indexing, continuous rotation, random color Gobo animation: Interchangeable animation wheel, indexing, continuous rotation with variable speed and direction Rotating gobo wheel: 5 x interchangeable texture/breakup gobos + open, indexing, continuous rotation and shake Iris: Variable 0 - 100% Zoom: Motorized Color temperature control: Variable 3000 - 7000 K Framing: Rotatable framing module, +/- 55°, 4 x individually controllable blades with variable angle and position Frost: Variable 0 - 100% Dimmer/shutter: 0 - 100% continuous dimming, regular and random strobe and pulse effects, instant open and blackout Dimming options: Choice of four dimming curves Pan: 540° Tilt: 268° Position correction system: Absolute position monitoring Focus: Range varies with zoom angle, from approx. 2 m (6.6 ft.) / 6 m (19.7 ft.) to infinity
  Control and Programming Setting and addressing: Control panel with backlit graphic display and jog wheel or via DMX 16-bit control: Dimming, rotating gobos, zoom, focus, pan and tilt Movement control options: Tracking and vector DMX channels: 38 Fixture Identification: User-settable ID number DMX compliance: USITT DMX512-A RDM compliance: ANSI/ESTA E1.20 Transceiver: Opto-isolated RS-485 Fixture software update: USB memory device or over DMX link
  Optics Zoom range: 12° - 48° one-tenth peak (1:4) Light source: 468 W custom Martin LED engine Minimum LED lifetime: 50,000 hours (to >80% luminous output)* *Figure obtained under manufacturer's test conditions
  Photometric Data Light engine luminous output: ≥ 31,500 lumens Fixture luminous output: 9,200 lumens CRI (Color Rendering Index) : >90 CQS (Color Quality Scale): >90 TM-30 Rf (IES TM-30-15 Fidelity Index): >90 TM-30 Rg (IES TM-30-15 Gamut Index): >98 TLCI (Television Lighting Consistency Index): >90 CCT: 3000 K (+/- 250 K)

  * All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.

  Construction Housing: High-impact flame-retardant thermoplastic Color: Black Protection rating: IP20
  Installation Mounting points: 4 pairs of 1/4-turn locks Location: Dry location only, must be fastened to surface or structure Orientation: Any Minimum distance to combustible materials: 0.2 m (8 in.) Minimum distance to illuminated surfaces: 2.0 m (6.6 ft.)
  Connections AC power input: Neutrik TRUE1 socket (accepts Neutrik TRUE1 NAC3FX-W connector) DMX and RDM data in/out: 5-pin locking XLR
• Electrical

  AC power: 120-240 V AC nominal, 50/60 Hz
  Power supply unit: Auto-ranging electronic switch mode
  Typical half-cycle RMS inrush current at 230 V, 50 Hz: 10.3 A
  Power Factor: 0.99 @ 120 V / 208 V / , 0.98 @ 230 V / 240 V
  Typical current draw: 5.0 A @ 120 V , 2.9 A @ 208 V , 2.6 A @ 230 V , 2.2 A @ 240 V *
  Power Consumption
  Typical: 596 W *
  Idle: 64 W *
  * Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
  Typical: full output white, no effects moving, regulated fan speed.
  Idle: no output, no effects moving, regulated fan speed.



  Thermal Cooling: Combined convection and forced air (temperature-regulated, low noise, user-definable levels) Maximum ambient temperature (Ta max.): 40° C (104° F) Minimum ambient temperature (Ta min.): 5° C (41° F) Maximum surface temperature, steady state, at 40° C ambient: 75° C (167° F) Total heat dissipation (calculated, +/- 10%): 2000 BTU/hr.
  Environmental RoHS: Compliant REACH: Compliant WEEE: Compliant Proposition 65: Compliant Efficacy (max output): 16 lm/w LWR*: 297 lm/kg (135 lm/lb)

  LWR = Lumen-to-Weight Ratio

  Approvals EU safety: EN 60598-2-17, EN 62471, EN62493 EU EMC: EN 55015, EN 55032, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547 US safety: UL 1573 US EMC: FCC Part 15 Class A Canadian safety: CSA C22.2 No. E598-2-17 Canadian EMC: ICES-003 Class A Australia/NZ: RCM Thailand: TIS
  Included Items Two omega brackets with 1/4 turn fasteners for rigging clamp attachment
  Related Items Martin Companion Cable: P/N 91616091 Martin Companion Cable (for firmware update over DMX): Free download from www.martin.com
  Accessories Gelframe MAC Encore: P/N 91001000 Set of Followspot Handles MAC Encore: P/N 91001001HU Heavy Frost Assy MAC Encore Performance: P/N 91001002HU SIP Packaging MAC Encore Family: P/N 91616115HU Static GOBO Wheel MAC Encore Performance: P/N 91001003 Top Hat MAC Encore Performance: P/N 91001004 Cables and connectors:

  Power Input Cable, H07RN-F, 2.5 mm2, bare ends to Neutrik TRUE1 NAC3FX-W (female), 1.5 m (4.9 ft.): P/N 91611797
  Power Input Cable, H07RN-F, 2.5 mm2, bare ends to Neutrik TRUE1 NAC3FX-W (female), 5 m (16.4 ft.): P/N 91611786
  Power Input Cable, SJOOW, 12 AWG, bare ends to TRUE1 NAC3FX-W (female), 1.5 m (4.9 ft.): P/N 91610173
  Power Input Cable, SJOOW, 12 AWG, bare ends to TRUE1 NAC3FX-W (female), 5 m (16.4 ft.): P/N 91610174
  Cable Connector, Neutrik PowerCON TRUE1 NAC3FX-W (female): P/N 91611789

  *Please order SIP variant fixtures to obtain the required SIP foam flightcase inserts Installation hardware:

  G-clamp (suspension with fixture hanging vertically downwards only): P/N 91602003
  Quick Trigger Clamp (suspension with fixture hanging vertically downwards only): P/N 91602007
  Half-coupler Clamp: P/N 91602005
  Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006
  Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007

  Flightcase: Two-unit Flightcase for MAC Encore™*: P/N 91515048
  Verified Third-Party Accessories

  Beam Control
  MAC Encore Performance Top Hat: P/N City Theatrical 2778



  Ordering Information MAC Encore™ Performance WRM EPS (in cardboard box, polystyrene packaging): P/N 90234015HU MAC Encore™ Performance WRM SIP (in cardboard box with SIP foam flightcase insert): P/N 90234016HU MAC Encore™ Performance WRM, white finish, EPS (in cardboard box, polystyrene packaging): P/N 90234020HU

•
