• Physical Length: 418 mm (16.5 in.) Width: 328 mm (13.0 in.) Height: 588 mm (23.2 in.) Weight: 18 kg (39.7 lbs.)
  Dynamic Effects Color wheel 1: 7 colors plus open, rotation with variable direction and speed Color wheel 2: 7 colors (incl. 1 x UV, 2 x CTC) plus open, rotation with variable direction and speed Rotating gobo wheel: 7 gobos plus open, wheel rotation, gobo indexing, rotation and shake Static gobo wheel: 8 gobos plus open, wheel rotation and shake Iris: Motorized Prism: Indexing and rotation with variable direction and speed Electronic dimming: 0 - 100%, four dimming curve options Electronic shutter effect: Strobe effect, pulse effects, instant open and blackout Pan: 540° Tilt: 270° Pan and tilt speed: Adjustable via onboard control panel and DMX Focus: Motorized
  Control and Programming Control options: DMX, standalone Setting and addressing: Control panel with backlit graphic display DMX channels: 17 Standalone trigger options: Music trig, auto trig Standalone sequences: 4 pre-programmed shows Standalone memory: 20 scenes Music trig sensitivity: Adjustable DMX compliance: USITT DMX512/1990
  Optics Light source: 180 W LED engine Minimum LED lifetime: 20,000 hours (to >70% luminous output)* *Figure obtained under manufacturer´s test conditions.
  Photometric Data Efficacy: 25.5 lumens per watt Cut-off angle: 16° Total output: 7100 lumen
  Construction Housing: High-impact flame-retardant thermoplastic Color: Black Protection rating: IP20
  Gobos Gobo diameter: 26.8 mm +/- 0.2 mm (1.1 in. +/- 0.008 in.) Maximum image diameter: 22.0 mm (0.87 in.) Gobo thickness, minimum: 0.3 mm (0.01 in.) Gobo thickness, maximum: 3.5 mm (0.14 in.) Gobo material: Steel, aluminum or borosilicate glass
• Installation Mounting points: Two quarter-turn brackets for rigging clamps Location: Dry location only, must be fastened to surface or structure Orientation: Any
  Electrical AC power: 100-240 V nominal, 50/60 Hz Typical total power consumption: 300 W Power consumption figures are typical, not maximum. Allow for +/-10% variation.
  Thermal Cooling: Forced air, temperature controlled Maximum ambient temperature (Ta max.): 40° C (104° F) Minimum ambient temperature (Ta min.): 0° C (32° F) Total heat dissipation (calculated, +/- 10%): 1010 BTU/hr. (at full intensity, full white)
  Approvals EU safety: EN 60598-2-17 (EN 60598-1), EN 62471, EN 62493 EU EMC: EN 55015, EN 55103-1, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547 US safety: UL 1573 US EMC: 47 CFR Part 15 Class A Australia/NZ: RCM
  Included Items

  Power cable, 1.5 m (4.9 ft.), without mains plug
  Two Omega clamp attachment brackets with 1/4-turn fasteners

  Related Items Martin™ RDM 5.5 Splitter: P/N 90758150 Martin Companion Cable: P/N 91616091 Martin Companion Software Suite (including firmware uploader): Free download from www.martin.com
  Accessories Power connectors:

  Power Connector PowerCON Male: P/N 91611795
  Power Connector PowerCON Female : P/N 91611794

  Cables, 16 A, for connection to power in chains:

  Power relay cable 3 x 2.5 mm2, H07RN-F POWCON-POWCON 1.2 m (3.9 ft.): P/N 91611798
  Power relay cable 3 x 14 AWG, SJOOW POWCON-POWCON 1.2m (3.9 ft.): P/N 91610175
  Power relay cable 3 x 2.5 mm2, H07RN-F POWCON-POWCON 2.5m (8.2 ft.): P/N 91611799
  Power relay cable 3 x 14 AWG, SJOOW POWCON-POWCON 2.5m (8.2 ft.): P/N 91610176

  Cables, 16 A, for power input:

  Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 1.5 m (4.9 ft.): P/N 91611800
  Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 1.5 m (4.9 ft.): P/N 91610177
  Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 5.0 m (16.4 ft.): P/N 91611801
  Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 5.0 m (16.4 ft.): P/N 91610178
  (H07RN-F are European approved cables, SJOOW are US approved cables)

  Installation hardware:

  G-clamp (suspension with fixture hanging vertically downwards only): P/N 91602003
  Quick trigger clamp (suspension with fixture hanging vertically downwards only): P/N 91602007
  Half-coupler clamp: P/N 91602005
  Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006
  Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007

  Ordering Information RUSH MH 1 Profile Plus™ in cardboard box: P/N 90280050

•
