Length: 480 mm (18.9 in.) *
Width: 19 mm (0.8 in.)
Height: 15 mm (0.6 in.)
Weight: 53 g (0.12 lbs.)

Length: 240 mm (9.5 in.) *
Width: 19 mm (0.8 in.)
Height: 15 mm (0.6 in.)
Weight: 32 g (0.07 lbs.)

Control modes, direct DMX control: Module and Pixel DMX channels, direct DMX control: 3/12/24 Control modes, DMX via P3: P3 Intensity, P3 RGB, P3 Basic, P3 Hybrid and P3 PixelMap DMX channels, DMX via P3: Wide range of options from 1 to 27

Brightness control
Gamma correction and control
Color temperature control
Color space control
Calibration processing
Synchronization

Pitch (pixel center-to-center): 60.00 mm Total output, calibrated mode: 750 nits (fixtures placed in continuous surface) Luminous output, calibrated mode: 135 lumen per meter LED Array VC-Strip 60 8x1: 8 x 1 LED Array VC-Strip 60 4x1: 4 x 1

* All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.

VC-Strip 60 8x1: 11 BTU/hr
VC-Strip 60 4x1: 6 BTU/hr

Power+Data Adapter, XLR4-to-PCB, 0.25 m (0.9 ft.): P/N 91616035
Power+Data Adapter, XLR5+Power-to-XLR4, 0.25 m (0.9 ft.): P/N 91616037
Power+Data Adapter, XLR5+XLR4-to-XLR4, 0.25 m (0.9 ft.): P/N 91616038
Power+Data Adapter, XLR5+Tripix-to-XLR4, 0.25 m (0.9 ft.): P/N 91616039

Power+Data Cable, PCB-to-PCB, 200 mm (7.9 in.): P/N 91616025
Power+Data Cable, PCB-to-PCB, 400 mm (15.8 in.): P/N 91616026
Power+Data Cable, PCB-to-PCB, 600 mm (23.7 in.): P/N 91616027
Power+Data Cable, PCB-to-PCB, 800 mm (31.5 in.): P/N 91616028
Power+Data Cable, PCB-to-PCB, 1000 mm (39.4 in.): P/N 91616029

Power+Data Cable, XLR4-to-XLR4, 1 m (3.3 ft.): P/N 91616030
Power+Data Cable, XLR4-to-XLR4, 2.5 m (8.2 ft.): P/N 91616031
Power+Data Cable, XLR4-to-XLR4, 5 m (16.4 ft.): P/N 91616032
Power+Data Cable, XLR4-to-XLR4, 10 m (32.8 ft.): P/N 91616033
Power+Data Cable, XLR4-to-XLR4, 25 m (82.1 ft.): P/N 91616034

Hybrid Output/Thru Cable, PCB-to-XLR4, 0.25 m (0.9 ft.): P/N 91616036
Power+Data Adapter, XLR4-to-XLR5, 0.25 m (0.9 ft.): P/N 91616040

Power+Data Cable, Rental, 100 m (328.1 ft.): P/N 91616045
Power+Data Cable, Install CMX, 100 m (328.1 ft.): P/N 91616060
Power+Data Cable, Install LSZH, 100 m (328.1 ft.): P/N 91616017
