THRILL Multi-FX LED (discontinued)

Larger Images

THRILL Multi-FX LED is a 3-in-1 LED light fixture with an impressive number of tricks up its sleeve, guaranteed to make your show larger than life. It is equipped with laser, strobe, and rotating colored multibeams with super bright output for a great variety of dazzling looks and mid-air effects.

With its high-speed, ultra-sharp laser beams, the THRILL Multi-FX LED is ideal for creating dramatic atmospheres and boosting energy levels in a variety of setups ranging from entertainment and club environments to wedding parties and corporate shows.

  • High-speed hybrid effect light fixture that energizes crowds with multibeams, laser and strobe effects
  • Easy plug-and-play control
  • Portable and lightweight
  • LET THE MUSIC DO THE TALKING

    THRILL Multi-FX LED is a perfect fit for musicians, DJs and home enthusiasts who want to spend their time focused on entertaining, rather than setting up and controlling complex equipment. For a literal plug and play experience, THRILL Multi-FX LED features a built-in microphone—simply turn on the sound trigger and let the beat of your music THRILL your audience. In addition, the fixture has eight, professionally-programmed shows that can be run either standalone or with daisy-chained units—no lighting experience required.

  • THE VALUE OF HYBRID

    The THRILL Multi-FX LED is a terrific value for money combining three energizing effects into one fixture. This is truly a Swiss army knife of lighting extravaganza. Perfect for performers who want to outfit their show with high intensity, stunning lighting effects, but have limited space for mounting and transporting equipment.

  • HUNDREDS OF LASER BEAMS

    The THRILL Multi-FX LED has an impressive laser effect engine consisting of independently controlled red and green lasers. Hundreds of laser beams project simultaneously, washing over the crowd, exciting the eye. The lasers have pre-defined shapes, patterns and movements which can be easily customized to suit your entertainment style.

  • SIMPLICITY IN SETUP AND CONTROL

    The THRILL Multi-FX LED is easy to control whether used as a standalone fixture or as part of a complete DMX control system. The THRILL Multi-FX LED can be easily manipulated via any standard DMX controller. In addition, you can daisy chain up to 32 fixtures in a master/client configuration.

  • NO COMPLEX PROGRAMMING

    Want to customize your live set and take things further than the 8 preset shows? No problem.
    The THRILL Multi-FX LED features several macros on each channel that you can use as a baseline in your programming. And when you need a break from controlling the lighting, easily put the fixture into the Integrated Show Control Mode via DMX, and let pre-programmed looks and a sound trigger do the work for you.

LET THE MUSIC DO THE TALKING

THRILL Multi-FX LED is a perfect fit for musicians, DJs and home enthusiasts who want to spend their time focused on entertaining, rather than setting up and controlling complex equipment. For a literal plug and play experience, THRILL Multi-FX LED features a built-in microphone—simply turn on the sound trigger and let the beat of your music THRILL your audience. In addition, the fixture has eight, professionally-programmed shows that can be run either standalone or with daisy-chained units—no lighting experience required.

THE VALUE OF HYBRID

The THRILL Multi-FX LED is a terrific value for money combining three energizing effects into one fixture. This is truly a Swiss army knife of lighting extravaganza. Perfect for performers who want to outfit their show with high intensity, stunning lighting effects, but have limited space for mounting and transporting equipment.

HUNDREDS OF LASER BEAMS

The THRILL Multi-FX LED has an impressive laser effect engine consisting of independently controlled red and green lasers. Hundreds of laser beams project simultaneously, washing over the crowd, exciting the eye. The lasers have pre-defined shapes, patterns and movements which can be easily customized to suit your entertainment style.

SIMPLICITY IN SETUP AND CONTROL

The THRILL Multi-FX LED is easy to control whether used as a standalone fixture or as part of a complete DMX control system. The THRILL Multi-FX LED can be easily manipulated via any standard DMX controller. In addition, you can daisy chain up to 32 fixtures in a master/client configuration.

NO COMPLEX PROGRAMMING

Want to customize your live set and take things further than the 8 preset shows? No problem.
The THRILL Multi-FX LED features several macros on each channel that you can use as a baseline in your programming. And when you need a break from controlling the lighting, easily put the fixture into the Integrated Show Control Mode via DMX, and let pre-programmed looks and a sound trigger do the work for you.

Videos





Features

  • Energizing multi-effect light featuring multibeam, laser, strobe
  • Vibrant 5 x 3 W RGBWA rotating multibeam effects
  • Blinding 8 x 1 W white LEDs for strobe effects
  • Projects hundreds of razor sharp laser beams with green and red lasers
  • Easy to operate standalone sound-activated, master/client control methods
  • 8 professionally pre-programmed shows
  • DMX operable for individualized control and design
  • Included adjustable bracket for hanging or surface mount
  • Common IEC mains inlet/thru – mains cable included

Specifications

PhysicalLength: 246 mm (9.7 in.)Length with hanging bracket: 307 mm (12.1 in.)Width: 234 mm (9.3 in.)Width with hanging bracket: 234 mm (9.3 in.)Height: 246 mm (9.7 in.)Height with hanging bracket: 286 mm (11.3 in.)Weight: 4.5 kg (9.8 lbs.)
Dynamic EffectsMultibeam effectsColor mixing: RGBWAColor selection: 36 color presetsElectronic dimming: 0-100%Strobe rate: 0-22 HzStrobe and pulse effects: Variable speed and action, random strobeElectronic 'shutter' effect: Instant open and blackoutStrobe effectsColor: WhiteStrobe rate: Fixed, 15 HzSpecial effects: On/off, strobe effect, pulse effects, random and blackoutLaser effectsColor: Red, greenSpecial effects: On/off, strobe effect, pulse effects, random and blackout
Control and ProgrammingControl options: DMX, stand-aloneSafety lockout switch, laser: Keyed switch on/off operationDMX channels: 2/16Stand-alone trigger options: Sound-trigger, auto-runUser interface: Control panel with LED displayDMX compliance: ANSI E1.11 - USITT DMX512-A
OpticsMultibeam and strobeMultibeam light source: 5 x 3 W RGBWA LEDsStrobe light source: 8 x 1 W White LEDsMinimum LED lifetime: 30 000 hours (to >70% luminous output)**Figure obtained under manufacturer's test conditionsLaserGreen laser, power / wavelength: 3.8 mW / 531 nmRed laser, power / wavelength: 1.5 mW / 659 nmAperture diameter: 7 mmBeam shape: DivergentPulse duration (frequency): Not pulsedClass: 3R (US: Class IIIR)Minimum laser lifetime: 3 000 hours**Figure obtained under manufacturer's test conditions
ConstructionHousing: SteelColor: BlackIngress protection: IP 20
InstallationMounting: Adjustable bracket, surface or truss mountMounting points: Bracket for single rigging clamp, M12 or ½”Orientation: Any (respecting laser precautions)Location: Indoor, dry locations only, overhead use onlyMinimum distance above floor level: 3 m (9.8 ft.)Minimum distance from public: 3 m (9.8 ft.)
ConnectionsAC power in/thru: IEC male inlet/female connector, C14/C13DMX data in/thru: 3-pin XLR
ElectricalAC power: 100-240 V nominal, 50/60 HzFuse: F 3 AL, 250 VTypical power consumption:: 35 W*Maximum number of fixtures on AC power throughput, 100-130 V: 6 x THRILL Multi-FX LED or 3 AMaximum number of fixtures on AC power throughput, 220-240 V: 10 x THRILL Multi-FX LED or 3 A*Power consumption figures are typical, not maximum. Allow for +/-10% variation.
Typical Power and Current110 V, 60 Hz: 0.5 A, 35 W *230 V, 50 Hz: 0.3 A, 35 W **Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%.
ThermalCooling: PassiveMaximum ambient temperature (Ta max.): 40° C (104° F)Minimum ambient temperature (Ta min.): 0° C (32° F)Total heat dissipation (calculated, +/- 10%) at full intensity, full white: 225 BTU/hr.
ApprovalsEU safety: EN 60598-1, EN 60598-2-17, EN 60825-1, EN 62031, EN 6247-1, EN 6247-2-13, EN 62493, IEC TR 62471-2EU EMC: EN 55015, EN 61000-3-2, EN 61000-3-3, EN 61547Australia/NZ (pending): RCM
Included ItemsPower cable, EU, IEC C13 female, molded Schuko, 1.5 m (4.9 ft.)Power cable, US, IEC C13 female, molded NEMA 5-15P, 1.5 m (4.9 ft.)Mounting bracket and hardwareSet of keys for laser safety switch
AccessoriesSuper lightweight half-coupler, black: P/N 91602018Safety cable, SWL 60 kg (132 lb.), BGV C1/ DGUV 17, black: P/N 91604006
Ordering InformationTHRILL Multi-FX LED: P/N 90280117
