• Physical

  Width (across yoke): 302 mm (11.89 in.)
  Width (base): 222 mm (8.74 in.)
  Height (head forward): 360 mm (14.17 in.)
  Height (maximum): 390 mm (15.35 in.)
  Depth (head): 163 mm (6.42 in.)
  Depth (base): 138 mm (5.43 in.)
  Minimum center-to-center distance in side-by-side installation: 320 mm (13 in.)
  Weight: 6.5 kg (14.4 lbs)

  Dynamic Effects

  Beam Dimmer/Shutter: 0 - 100% continuous dimming, regular and random strobe/pulse/burst, instant open and blackout
  Beam Dimming options: Choice of four dimming curves
  Beam Color Mixing: RGB (RGBW in Raw Mode), independently variable 0 - 100%
  Beam Color Temperature Control: Variable 2,500 – 10,000 K
  Beam Virtual Color wheel: 33 color presets, continuous rotation & random color
  Zoom: Motorized with 1:6 zoom ratio
  Pan: Motorized 540°
  Tilt: Motorized 232°
  Aura Dimmer/Shutter: 0 – 100% continuous dimming, regular and random strobe/pulse/burst effects, instant open and blackout
  Aura Dimming options: Choice of four dimming curves
  Aura Color Mixing: RGB, independently variable 0 - 100%
  Aura Virtual Color wheel: 33 color presets, continuous rotation & random color
  Pre-programmed effects: Two ranges of FX on Beam, Aura or Combination; independent or synchronized/combined

  Control and Programming

  Control Protocols: DMX and RDM
  DMX Modes: Standard & Extended
  DMX Channels: 14 & 25
  16-bit Controllable Parameters: Pan and Tilt
  Setting and Addressing: Display Menu or RDM
  Local User Interface: Backlit LCD Display
  DMX Compliance: USITT DMX512-A
  RDM Compliance: ANSI/ESTA E1.20
  DMX/RDM Transceiver: Galvanic-isolated RS-485
  Firmware Update: via DMX using Martin Companion

  Optics

  Front Lens Diameter: 200 mm (7.87 in.)
  Zoom Range: 1:6
  Full Zoom Range at Half Peak (Beam Angle): 9.0° - 41.7°
  Full Zoom Range at Tenth Peak (Field Angle): 10.3° - 59.1°
  Beam Light Source: 19 x 15 W RGBW LED
  Aura Light Source: 30 x 0.3 W RGB LED
  Max. Total Beam LED Engine Power: 285 W
  Max. Total Aura LED Engine Power: 9 W
  Minimum LED lifetime: > 50.000 hours (to > 70% luminous output)*
  *Figure obtained under manufacturer's test conditions

  Photometric Data

  Light Engine Luminous Output: 10,000 lumens
  Fixture Luminous Output Wide: 6,000 lumens
  Fixture Luminous Output Narrow: 4,300 lumens
  Peak Luminous Intensity Narrow: 220,000 cd
  CCT: Variable 2,500 K – 10,000 K (+/- 200 K)
  CRI (Color Rendering Index): ≥ 67
  CQS (Color Quality Scale): ≥ 82
  TM-30 Rf (IES TM-30-15 Fidelity Index): ≥ 76
  TM-30 Rg (IES TM-30-15 Gamut Index): ≥ 119
  TLCI (Television Lighting Consistency Index): ≥ 48
  Beam LED Refresh Rate: 1,200 Hz
  Aura LED Refresh Rate: 4,395 Hz
  Binning: Tight color and flux binning
  Calibration: Full Gamut Color Calibration of Beam and Aura
  Color Modes: Extended Color Mode, Calibrated Color Mode and Raw Color Mode
  * All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient
  * All Photometric Data measured at 6500 K white


  Construction Housing: High-impact thermoplastic, flame-retardant to UL 94 5VA Color: Black Protection rating: IP20
  Installation Mounting points: M12 threaded hole for rigging clamp and attachment points for surface-mounting bracket Location: Indoor Orientation: Any Minimum distance to combustible materials: 0.2 m (7.87 in.) Minimum distance to illuminated surfaces: 1.0 m (39.37 in.)
  Connections AC mains power in/thru: Neutrik powerCON TRUE1 DMX and RDM data in/thru: Neutrik 5-pin locking XLR
  Electrical

  AC power: 100-240 V AC nominal, 50/60 Hz
  Power supply unit: Auto-ranging electronic switch mode
  Typical half-cycle RMS inrush current at 230 V, 50 Hz: 10.7 A
  Power Factor: 0.99 @ 100 V / 120 V , 0.97 @ 208 V , 0.95 @ 230 V / 240 V
  Max current draw: 3.8 A @ 100 V / 120 V , 1.8 A @ 208 V / 230 V / 240 V
  Typical current draw: 3.8 A @ 100 V , 3.2 A @ 120 V , 1.8 A @ 208 V , 1.7 A @ 230 V , 1.6 A @ 240 V *
  Power Consumption
  Maximum: 400 W
  Typical: 359 W *
  Idle: 25 W *
  * Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
  Typical: full output white, no effects moving, regulated fan speed.
  Idle: no output, no effects moving, regulated fan speed.

• Thermal Cooling: Forced air (temperature-regulated, low noise, user-definable levels) Maximum ambient temperature (Ta max.): 40° C (104° F) Minimum ambient temperature (Ta min.): 5° C (41° F) Total heat dissipation (calculated, +/- 10%): 1230 BTU/hr.
  Acoustic Data Sound Pressure Level (LpA) @ 1 m (default regulated fan mode, full output): 28.9 dB(A)
  Environmental RoHS: Compliant REACH: Compliant WEEE: Compliant Proposition 65: Compliant Efficacy (max output): 26.7 lm/W LWR*: 923 lm/kg (417 lm/lb)

  LWR = Lumen-to-Weight Ratio

  Approvals EU safety: EN 60598-2-17 (EN 60598-1), EN 62471 EU EMC: EN 55103-1, EN 55103-2, EN 55015, EN 61547 US safety: UL 1573 US EMC: FCC Part 15 Class A Canadian safety: CSA E598-2-17 (CSA E60598-1) Canadian EMC: ICES-003 Class A Australia/NZ: C-TICK N4241 United Kingdom: UKCA Thailand: TIS
  Included Items

  M12 bolt suitable for use with Martin rigging clamps
  User Manual in Eng/Fre/Ger

  Related Items Martin Companion Cable (for firmware update over DMX): P/N 91616091 Martin Companion Software (for firmware update over DMX): Free download from www.martin.com
  Accessories

  Optical
  MAC Aura XB SoftLens: P/N 91611730HU

  Transport and Storage
  Flightcase for 6 x MAC Aura XB: P/N 91515020

  Power Input Cables
  Power Input Cable, H07RN-F, 2.5 mm2, bare ends to TRUE1 NAC3FX-W TOP (female), 1.5 m (4.9 ft.) P/N 91611797
  Power Input Cable, SJOOW, 12 AWG, bare ends to TRUE1 NAC3FX-W TOP (female), 1.5 m (4.9 ft.) P/N 91610173

  Power Linking Cables
  Power relay cable, H07RN-F, 2.5 mm2, TRUE1 to TRUE1, 2.5 m (8.2 ft.): P/N 91611796
  Power relay cable, SJOOW, 12 AWG, TRUE1 to TRUE1, 2.5 m (8.2 ft.): P/N 91610172

  Power Connectors
  Cable Connector, Neutrik powerCON TRUE1 TOP Female: P/N 91611789HU
  Cable Connector, Neutrik PowerCON TRUE1 TOP Male: P/N 91611788HU

  Installation Hardware
  Quick surface mounting bracket for MAC Aura XB, set of 5: P/N 91606018
  G-clamp (suspension with fixture hanging vertically downwards only): P/N 91602003
  Quick Trigger Clamp (suspension with fixture hanging vertically downwards only): P/N 91602007
  Half-coupler Clamp: P/N 91602005
  Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006
  Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007

  Verified Third-Party Accessories

  Beam Control
  MAC Aura XB Top Hat: P/N City Theatrical 2792
  MAC Aura XB Egg Crate: P/N City Theatrical 2793
  MAC Aura XB Concentric Rings: P/N City Theatrical 2791
  MAC Aura XB Beam Control Accessory Mount Kit: P/N City Theatrical 104-00117


  Ordering Information MAC Aura XB™ in cardboard box: P/N 90232100HU MAC Aura XB™ in 6-unit flightcase: P/N 90232110HU MAC Aura XB™ white in cardboard box: P/N 90232105HU

•
